REVERSE SHIFT LEVER ASSEMBLY для Arctic Cat 500 4X4 AUTO (GREEN) [A2002ATM4BUSG] - 2002 года выпуска
-
№АртикулНазвание
-
18424-602 NUTNUT
-
28408-812 SCREW, CAPSCREW, CAP
-
30502-187 AXLE, REVERSE LEVERAXLE, REVERSE LEVER
-
40502-185 LEVER, SHIFTLEVER, SHIFT
-
50423-299 O-RINGO-RING
-
60423-182 O-RINGO-RING
-
70423-087 WASHERWASHER
-
80402-678 SPRING, REVERSE LEVERSPRING, REVERSE LEVER
-
90402-675 AXLE, PIVOTAXLE, PIVOT
-
100402-843 HANDLE, REVERSE LEVERHANDLE, REVERSE LEVER
-
110423-345 CLIP, PUSHCLIP, PUSH
-
120502-188 LINKAGE, SHIFTLINKAGE, SHIFT
-
130402-844 END, RODEND, ROD
-
140623-294 NUTNUT
-
150423-091 BUSHING, SHIFTBUSHING, SHIFT
-
168050-242 WASHERWASHER
-
170423-169 E-RINGE-RING
-
180402-685 PLATE, SHIFTPLATE, SHIFT
-
190406-943 SHIELD, LINKAGESHIELD, LINKAGE
-
200423-371 SCREW, MACHINESCREW, MACHINE
-
210623-309 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
