WHEEL AND TIRE ASSEMBLY для Arctic Cat 550 H1 (RED) [A2009IBO4EUSR] - 2009 года выпуска
-
№АртикулНазвание
-
10423-557 SCREW, SHOULDERSCREW, SHOULDER
-
21436-164 DISC, BRAKEDISC, BRAKE
-
33323-100 HUB, WHEEL - FRONT (INC. 4)HUB, WHEEL - FRONT (INC. 4)
-
40402-974 ...STUD...STUD
-
53323-113 HUB, WHEEL - REAR - LEFT (INC. 4)HUB, WHEEL - REAR - LEFT (INC. 4)
-
53323-100 HUB, WHEEL - REAR - RIGHT (INC. 4)HUB, WHEEL - REAR - RIGHT (INC. 4)
-
60423-607 NUT, CASTLENUT, CASTLE
-
70423-407 PIN, COTTERPIN, COTTER
-
81402-776 WHEEL - FRONT - PLATINUM (ALL EXCEPT GREEN & CAMO)WHEEL - FRONT - PLATINUM (ALL EXCEPT GREEN & CAMO)
-
81402-777 WHEEL - REAR - PLATINUM (ALL EXCEPT GREEN & CAMO)WHEEL - REAR - PLATINUM (ALL EXCEPT GREEN & CAMO)
-
81402-778 WHEEL - FRONT - GRAY (GREEN)WHEEL - FRONT - GRAY (GREEN)
-
81402-779 WHEEL - REAR - GRAY (GREEN)WHEEL - REAR - GRAY (GREEN)
-
81402-780 WHEEL - FRONT - BLACK (M4 CAMO)WHEEL - FRONT - BLACK (M4 CAMO)
-
81402-781 WHEEL - REAR - BLACK (M4 CAMO)WHEEL - REAR - BLACK (M4 CAMO)
-
90423-408 NUT, LUGNUT, LUG
-
101402-658 TIRE, DUNLOP-AT25X8-12 QUADMAX - FRONTTIRE, DUNLOP-AT25X8-12 QUADMAX - FRONT
-
101402-659 TIRE, DUNLOP-AT25X10-12 QUADMAX - REARTIRE, DUNLOP-AT25X10-12 QUADMAX - REAR
-
110402-064 STEM, VALVE (INC. 12)STEM, VALVE (INC. 12)
-
120402-140 ...CAP, VALVE STEM...CAP, VALVE STEM
