DASH ASSEMBLY для Arctic Cat PROWLER XTZ - EURO (SUNSET ORANGE) [U2009P4W4EOSK] - 2009 года выпуска
-
№АртикулНазвание
-
12406-779 PANEL, DASHPANEL, DASH
-
21406-727 POD, INSTRUMENT - BLACKPOD, INSTRUMENT - BLACK
-
30520-047 GAUGE, ANALOG/LCDGAUGE, ANALOG/LCD
-
40423-342 SCREW, SELF TAPPING-.1875 X .75SCREW, SELF TAPPING-.1875 X .75
-
50623-784 SCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLKSCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLK
-
60420-065 BRACKET, RETAININGBRACKET, RETAINING
-
70423-493 NUT W/WASHERNUT W/WASHER
-
80641-897 OUTLET, ACCESSORY - 12VOUTLET, ACCESSORY - 12V
-
90409-069 PANEL, SWITCH-MOUNTPANEL, SWITCH-MOUNT
-
100409-067 SWITCH, LIGHTSWITCH, LIGHT
-
110409-061 SWITCH, 2WD/4WD/DIFFERENTIAL LOCKSWITCH, 2WD/4WD/DIFFERENTIAL LOCK
-
120409-070 PLUG, SWITCH HOLEPLUG, SWITCH HOLE
-
130430-089 SWITCH, IGNITION (INC. 14-16)SWITCH, IGNITION (INC. 14-16)
-
140430-050 NUT, FLANGE - IGNITION SWITCHNUT, FLANGE - IGNITION SWITCH
-
150430-042 KEY, IGNITION-SERIES (Y) (LEFT SIDE KEY)KEY, IGNITION-SERIES (Y) (LEFT SIDE KEY)
-
150430-043 KEY, IGNITION-SERIES (Z) (RIGHT SIDE KEY)KEY, IGNITION-SERIES (Z) (RIGHT SIDE KEY)
-
160430-054 COVER, KEYCOVER, KEY
-
171406-789 COVER, GLOVE BOX - BLACKCOVER, GLOVE BOX - BLACK
-
180423-541 GROMMET, LATCH - GLOVE BOXGROMMET, LATCH - GLOVE BOX
-
190420-076 LIGHT, INDICATORLIGHT, INDICATOR
-
201411-124 DECAL, WARNING - DIFFERENTIAL LOCKDECAL, WARNING - DIFFERENTIAL LOCK
-
211411-125 DECAL, WARNING - DASHDECAL, WARNING - DASH
-
221411-904 DECAL, STARTINGDECAL, STARTING
-
231623-697 PLUGPLUG
-
240423-419 SCREW, MACH-TSTRH-M6-1.0 X 16 BLACKSCREW, MACH-TSTRH-M6-1.0 X 16 BLACK
