WHEEL AND TIRE ASSEMBLY для Arctic Cat 700 MUD PRO LTD ORANGE [A2012MLT1PUSY] - 2012 года выпуска
-
№АртикулНазвание
-
0423-557 SCREW, SHOULDERSCREW, SHOULDER
-
21436-418 DISC, BRAKEDISC, BRAKE
-
31502-462 HUB, WHEEL - FRONT (INC. 4)HUB, WHEEL - FRONT (INC. 4)
-
40402-974 ...STUD...STUD
-
51502-462 HUB, WHEEL - REAR - RIGHT (INC. 4)HUB, WHEEL - REAR - RIGHT (INC. 4)
-
51502-464 HUB, WHEEL - REAR - LEFT (INC. 4)HUB, WHEEL - REAR - LEFT (INC. 4)
-
60423-607 NUT, CASTLENUT, CASTLE
-
70423-407 PIN, COTTERPIN, COTTER
-
81402-732 WHEEL - FRONT - ALUMINUM (INC. 9)WHEEL - FRONT - ALUMINUM (INC. 9)
-
91402-736 ...CAP, WHEEL...CAP, WHEEL
-
100402-064 STEM, VALVE (INC. 11)STEM, VALVE (INC. 11)
-
110402-140 ...CAP, VALVE STEM...CAP, VALVE STEM
-
120423-618 NUT, LUG - CHROMENUT, LUG - CHROME
-
131402-855 TIRE - FRONTTIRE - FRONT
-
141402-918 WHEEL - REAR - ALUMINUM (INC. 9)WHEEL - REAR - ALUMINUM (INC. 9)
-
151402-901 TIRE - REARTIRE - REAR
