FRONT BRAKE ASSEMBLY для Arctic Cat PROWLER XTX GRAY [A2012P3T1PUSV] - 2012 года выпуска
-
№АртикулНазвание
-
10502-786 CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 2-4)CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 2-4)
-
20405-225 ...CAP, RESERVOIR...CAP, RESERVOIR
-
30402-592 ...NUT...NUT
-
41402-520 ...CLEVIS...CLEVIS
-
51402-377 PIN, CLEVIS-1/4X51/64 Z & YPIN, CLEVIS-1/4X51/64 Z & Y
-
68050-217 WASHER, FLAT- 1/4 X .625 X .065 Z & YWASHER, FLAT- 1/4 X .625 X .065 Z & Y
-
70117-868 PIN, COTTER - 1/16 X 3/4PIN, COTTER - 1/16 X 3/4
-
88424-802 NUTNUT
-
98408-860 SCREW, CAPSCREW, CAP
-
100423-178 WASHER, CRUSHWASHER, CRUSH
-
110423-610 BOLT, DOUBLE BANJO-FITTINGBOLT, DOUBLE BANJO-FITTING
-
120423-413 BOLT, BANJO-FITTINGBOLT, BANJO-FITTING
-
131402-389 HOSE, BRAKE - LEFTHOSE, BRAKE - LEFT
-
141402-290 HOSE, BRAKE - RIGHTHOSE, BRAKE - RIGHT
-
151502-730 CALIPER, BRAKE - FRONT RIGHT (INC. 16-22)CALIPER, BRAKE - FRONT RIGHT (INC. 16-22)
-
151502-731 CALIPER, BRAKE - FRONT LEFT (INC. 16-22)CALIPER, BRAKE - FRONT LEFT (INC. 16-22)
-
161436-160 ...HOUSING, CALIPER - ASSEMBLY - FRONT RIGHT (INC. 17-19)...HOUSING, CALIPER - ASSEMBLY - FRONT RIGHT (INC. 17-19)
-
161436-161 ...HOUSING, CALIPER - ASSEMBLY - FRONT LEFT (INC. 17-19)...HOUSING, CALIPER - ASSEMBLY - FRONT LEFT (INC. 17-19)
-
170502-606 ......PISTON/SEAL SET (INC. 18)......PISTON/SEAL SET (INC. 18)
-
180502-607 ......SEAL SET......SEAL SET
-
190502-609 ......VALVE, BLEED......VALVE, BLEED
-
200502-608 ...O-RING, GUIDE - SET...O-RING, GUIDE - SET
-
210502-960 ...BRACKET ASSEMBLY...BRACKET ASSEMBLY
-
221502-694 ...PAD, BRAKE - SET...PAD, BRAKE - SET
-
238408-826 SCREW, CAPSCREW, CAP
-
240502-785 SPRING, BRAKE SWITCHSPRING, BRAKE SWITCH
-
250409-089 SWITCH, BRAKE - ASSEMBLYSWITCH, BRAKE - ASSEMBLY
-
261502-692 LEVER, BRAKELEVER, BRAKE
-
271602-213 O-RINGO-RING
-
280623-044 WASHERWASHER
-
298408-822 SCREW, CAPSCREW, CAP
