CARBURETOR ASSEMBLY для Arctic Cat 90 Utility [A2014KUB2BUSR] - 2014 года выпуска
-
№АртикулНазвание
-
-3306-829 COMPLETE CARBURETOR ASSEMBLYCOMPLETE CARBURETOR ASSEMBLY
-
13304-462 SET, TOP (INC. 2)SET, TOP (INC. 2)
-
23304-463 ...GASKET...GASKET
-
33304-464 SPRING, COMPRESSIONSPRING, COMPRESSION
-
43306-905 VALVE, THROTTLE - ASSEMBLY (INC. 5-7)VALVE, THROTTLE - ASSEMBLY (INC. 5-7)
-
53304-465 ...CLIP, SPRING...CLIP, SPRING
-
63304-466 ...E-RING...E-RING
-
73305-592 ...NEEDLE JET...NEEDLE JET
-
83304-468 NEEDLE JETNEEDLE JET
-
93304-472 HOSE ASSEMBLY (INC. ONE NO. 10)HOSE ASSEMBLY (INC. ONE NO. 10)
-
105507-161 ...CLAMP, HOSE...CLAMP, HOSE
-
113304-469 COVERCOVER
-
123304-470 AUTOMATIC BYPASS/STARTER ASSEMBLYAUTOMATIC BYPASS/STARTER ASSEMBLY
-
135507-117 SCREW, MACHINESCREW, MACHINE
-
143304-471 PLATE, RETAININGPLATE, RETAINING
-
153304-488 O-RINGO-RING
-
163304-477 SCREW, STOP - ASSEMBLY (INC. 17-18)SCREW, STOP - ASSEMBLY (INC. 17-18)
-
173304-232 ...SPRING...SPRING
-
183304-478 ...SCREW, STOP...SCREW, STOP
-
193304-479 HOLDER, NEEDLE JET - ASSEMBLY (INC. 20)HOLDER, NEEDLE JET - ASSEMBLY (INC. 20)
-
203304-482 ...JET, MAIN - 80...JET, MAIN - 80
-
205507-170 ...JET, MAIN - 75 - OPTIONAL...JET, MAIN - 75 - OPTIONAL
-
205507-220 ...JET, MAIN - 78 - OPTIONAL...JET, MAIN - 78 - OPTIONAL
-
213304-489 JET, SLOWJET, SLOW
-
223304-490 VALVE, FLOAT - ASSEMBLY (INC. 23-24)VALVE, FLOAT - ASSEMBLY (INC. 23-24)
-
233306-752 ...VALVE, FLOAT...VALVE, FLOAT
-
243304-484 ...CLIP...CLIP
-
253304-491 FLOAT ASSEMBLYFLOAT ASSEMBLY
-
263304-485 PIN, FLOATPIN, FLOAT
-
273304-486 CHAMBER, FLOAT W/GASKET (INC. ONE NO. 10 AND 28-30)CHAMBER, FLOAT W/GASKET (INC. ONE NO. 10 AND 28-30)
-
283304-239 ...O-RING...O-RING
-
293304-243 ...SCREW, DRAIN...SCREW, DRAIN
-
303305-248 ...HOSE...HOSE
-
313303-320 SCREW, MACHINESCREW, MACHINE
