TRANSMISSION LEFT-SIDE ASSEMBLY для Arctic Cat SUPER DUTY DIESEL 700 4X4 [A2014TBT4DUSG] - 2014 года выпуска
-
№АртикулНазвание
-
10832-050 BEARINGBEARING
-
20828-010 WASHER, THRUSTWASHER, THRUST
-
30822-140 GEAR, DRIVE (18T)GEAR, DRIVE (18T)
-
40822-124 COUNTERSHAFT ASSEMBLY (INC. 5-13)COUNTERSHAFT ASSEMBLY (INC. 5-13)
-
50831-085 ...RING, RETAINING...RING, RETAINING
-
60822-120 ...GEAR SELECT, REVERSE...GEAR SELECT, REVERSE
-
70822-121 ...SHIM...SHIM
-
80822-119 ...GEAR, REVERSE DRIVEN...GEAR, REVERSE DRIVEN
-
90832-082 ...BEARING...BEARING
-
100822-114 ...GEAR, DRIVEN - LOW...GEAR, DRIVEN - LOW
-
110822-113 ...COUNTERSHAFT...COUNTERSHAFT
-
120822-116 ...GEAR SELECT, SLIDING...GEAR SELECT, SLIDING
-
130822-115 ...GEAR, DRIVEN - HIGH...GEAR, DRIVEN - HIGH
-
140828-011 WASHERWASHER
-
150818-072 FORK, SHIFTFORK, SHIFT
-
160818-006 SHAFT, SHIFT FORKSHAFT, SHIFT FORK
-
170822-052 SEAL, COUNTERSHAFT - RIGHTSEAL, COUNTERSHAFT - RIGHT
-
180831-040 RING, RETAININGRING, RETAINING
-
190822-050 TRIGGER, SPEEDOMETER SENSORTRIGGER, SPEEDOMETER SENSOR
-
200828-069 WASHER, THRUSTWASHER, THRUST
-
210831-039 RING, RETAININGRING, RETAINING
-
220830-129 GASKETGASKET
-
230829-023 PIN, DOWELPIN, DOWEL
-
240822-049 HOUSING, SPEEDOMETER SENSORHOUSING, SPEEDOMETER SENSOR
-
250830-107 GASKETGASKET
-
268468-645 SCREW, MACHINESCREW, MACHINE
-
270824-042 SENSOR, SPEEDOMETERSENSOR, SPEEDOMETER
-
288468-620 SCREW, MACHINESCREW, MACHINE
-
290828-038 WASHERWASHER
-
300818-002 STOPPER, CAMSTOPPER, CAM
-
310818-004 SUPPORT, CAM STOPPERSUPPORT, CAM STOPPER
-
320818-090 SPRINGSPRING
-
330828-035 WASHERWASHER
-
348424-602 NUTNUT
-
350828-036 WASHERWASHER
-
360831-010 RING, RETAININGRING, RETAINING
-
370818-007 SUB-SHAFT - GEAR SHIFTSUB-SHAFT - GEAR SHIFT
-
381402-557 GASKET, COVER - SELECTORGASKET, COVER - SELECTOR
-
391502-009 COVER, SELECTORCOVER, SELECTOR
-
408405-620 SCREW, CAPSCREW, CAP
-
410830-044 SEALSEAL
-
420818-014 ARM, SELECTORARM, SELECTOR
-
431402-556 STOP, SPRING - SELECTORSTOP, SPRING - SELECTOR
-
440818-005 PLATE, GEAR SHIFT CAMPLATE, GEAR SHIFT CAM
-
450826-006 SCREW, CAPSCREW, CAP
-
460812-006 PLUG, DRAIN - MAGNETICPLUG, DRAIN - MAGNETIC
-
470830-017 GASKET, COMPRESSIONGASKET, COMPRESSION
-
481402-102 FITTING, ELBOWFITTING, ELBOW
-
490402-333 PLUG, FILL (INC. 50)PLUG, FILL (INC. 50)
-
500423-154 ...O-RING...O-RING
-
510470-689 LEVEL STICK, LUBRICANTLEVEL STICK, LUBRICANT
-
522506-388 TUBE, LEVEL STICKTUBE, LEVEL STICK
-
530423-465 GROMMETGROMMET
-
542506-445 BRACKET, LEVEL STICK TUBEBRACKET, LEVEL STICK TUBE
-
550423-715 O-RINGO-RING
-
560423-396 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
570827-013 NUTNUT
-
580828-020 WASHERWASHER
-
590819-005 FLANGE, OUTPUT JOINT - ASSEMBLYFLANGE, OUTPUT JOINT - ASSEMBLY
-
600830-043 SEAL, OILSEAL, OIL
-
610819-011 RING, DRIVEN BEARINGRING, DRIVEN BEARING
-
620832-016 BEARINGBEARING
-
631402-555 SLEEVESLEEVE
-
641402-867 GEAR, SECONDARY DRIVENGEAR, SECONDARY DRIVEN
-
651402-864 SPACERSPACER
-
661402-554 SHAFT, OUTPUT - SECONDARYSHAFT, OUTPUT - SECONDARY
-
670828-021 SHIM, 25 X 34 X 0.25 MMSHIM, 25 X 34 X 0.25 MM
-
670828-022 SHIM, 25 X 34 X 0.30 MMSHIM, 25 X 34 X 0.30 MM
-
670828-023 SHIM, 25 X 34 X 0.70 MMSHIM, 25 X 34 X 0.70 MM
-
670828-024 SHIM, 25 X 34 X 0.90 MMSHIM, 25 X 34 X 0.90 MM
-
670828-025 SHIM, 25 X 34 X 0.95 MMSHIM, 25 X 34 X 0.95 MM
-
670828-026 SHIM, 25 X 34 X 1.00 MMSHIM, 25 X 34 X 1.00 MM
-
670828-027 SHIM, 25 X 34 X 1.05 MMSHIM, 25 X 34 X 1.05 MM
-
670828-028 SHIM, 25 X 34 X 1.10 MMSHIM, 25 X 34 X 1.10 MM
-
670828-029 SHIM, 25 X 34 X 1.15 MMSHIM, 25 X 34 X 1.15 MM
-
680832-017 BEARING, DRIVEN SHAFTBEARING, DRIVEN SHAFT
-
690819-061 YOKE, DRIVE OUTPUT - FRONT ASSEMBLYYOKE, DRIVE OUTPUT - FRONT ASSEMBLY
-
701402-164 JOINT, UNIVERSAL - SET (INC. 71)JOINT, UNIVERSAL - SET (INC. 71)
-
710423-450 ...RING, RETAINING...RING, RETAINING
-
720819-063 YOKE, PROPELLER SHAFTYOKE, PROPELLER SHAFT
