CASE/BELT COOLING ASSEMBLY для Arctic Cat Wildcat X RED [U2014WSW1PUSE] - 2014 года выпуска
-
№АртикулНазвание
-
12416-974 SHIELD, HEATSHIELD, HEAT
-
20423-577 CLIP, U-NUTCLIP, U-NUT
-
30423-609 SCREW, MACHINESCREW, MACHINE
-
40470-945 GROMMETGROMMET
-
50413-295 DUCT, AIR-INDUCT, AIR-IN
-
60423-057 CLAMPCLAMP
-
70413-294 BOOT, AIR-INBOOT, AIR-IN
-
88476-625 SCREW, MACHINESCREW, MACHINE
-
90423-669 SPACERSPACER
-
100423-465 GROMMETGROMMET
-
110513-047 DUCT, AIR-OUT (INC. 12)DUCT, AIR-OUT (INC. 12)
-
120413-307 ...FOIL, PROTECTIVE...FOIL, PROTECTIVE
-
132416-818 BRACKET, SUPPORTBRACKET, SUPPORT
-
140413-296 BOOT, AIR-OUTBOOT, AIR-OUT
