REAR SUSPENSION ASSEMBLY для Arctic Cat WILDCAT SPORT XT BLUE [U2015W7T4COSD] (INTERNATIONAL) - 2015 года выпуска
-
№АртикулНазвание
-
10404-498 SHOCK ABSORBER - RIGHT (INC. 2-9)SHOCK ABSORBER - RIGHT (INC. 2-9)
-
10404-499 SHOCK ABSORBER - LEFT (INC. 2-9)SHOCK ABSORBER - LEFT (INC. 2-9)
-
20403-506 ...BEARING...BEARING
-
30403-507 ...CLIP...CLIP
-
40403-504 ...O-RING...O-RING
-
50403-508 ...SPACER...SPACER
-
60403-500 ...NUT, RETAINER - SPRING...NUT, RETAINER - SPRING
-
70403-501 ...SCREW, SET...SCREW, SET
-
80403-502 ...RETAINER...RETAINER
-
90403-503 ...CLIP...CLIP
-
108409-055 SCREW, CAPSCREW, CAP
-
110504-991 SPRING, SUSPENSION - WHITESPRING, SUSPENSION - WHITE
-
121423-266 SCREW, CAPSCREW, CAP
-
131423-334 NUT, LOCKNUT, LOCK
-
141504-060 A-ARM, REAR - UPPER LEFT - BLUE (INC. 15-17)A-ARM, REAR - UPPER LEFT - BLUE (INC. 15-17)
-
150404-503 ...SLEEVE...SLEEVE
-
162402-077 ...BEARING...BEARING
-
171423-287 ...SEAL...SEAL
-
181504-056 A-ARM, REAR - LOWER RIGHT - BLUE (INC. 15-17 AND 19)A-ARM, REAR - LOWER RIGHT - BLUE (INC. 15-17 AND 19)
-
181504-057 A-ARM, REAR - LOWER LEFT - BLUE (INC. 15-17 AND 19)A-ARM, REAR - LOWER LEFT - BLUE (INC. 15-17 AND 19)
-
190404-501 ...SLEEVE...SLEEVE
-
208413-090 SCREW, CAPSCREW, CAP
-
212502-355 KIT, HALFSHAFT (INC. 22-26)KIT, HALFSHAFT (INC. 22-26)
-
222436-111 ...REPAIR KIT, BOOT (INC. 23)...REPAIR KIT, BOOT (INC. 23)
-
231441-988 ......CLIP, RETAINING......CLIP, RETAINING
-
241402-884 ...PIN, DETENT...PIN, DETENT
-
251402-963 ...O-RING...O-RING
-
261402-890 ...CLIP, RETAINING...CLIP, RETAINING
-
271504-066 KNUCKLE, REAR - ASSEMBLY (INC. 16-17, 19 AND 27-28)KNUCKLE, REAR - ASSEMBLY (INC. 16-17, 19 AND 27-28)
-
281402-809 ...BEARING...BEARING
-
290423-423 RING, RETAININGRING, RETAINING
