CONSOLE AND INSTRUMENT ASSEMBLY для Arctic Cat XR 700 GREEN [A2015XAT4EUSG] - 2015 года выпуска
-
№АртикулНазвание
-
10405-522 CONSOLE, GAUGE - BLACKCONSOLE, GAUGE - BLACK
-
21423-284 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
30423-609 SCREW, MACHINESCREW, MACHINE
-
40423-577 CLIP, U-NUTCLIP, U-NUT
-
50520-268 GAUGE, LCD (INC. 6)GAUGE, LCD (INC. 6)
-
60409-161 ...RING, MOUNT - GAUGE...RING, MOUNT - GAUGE
-
70430-090 SWITCH, IGNITION - ASSEMBLY (INC. 8-10)SWITCH, IGNITION - ASSEMBLY (INC. 8-10)
-
80430-112 ...NUT, RETAINING...NUT, RETAINING
-
90430-109 ...KEY, IGNITION - A...KEY, IGNITION - A
-
90430-110 ...KEY, IGNITION - B...KEY, IGNITION - B
-
100430-111 ...COVER, KEY...COVER, KEY
-
110641-897 OUTLET, ACCESSORY - 12VOUTLET, ACCESSORY - 12V
-
124406-713 CONSOLE, REAR - BLACKCONSOLE, REAR - BLACK
-
134406-340 PANEL, WINDSCREENPANEL, WINDSCREEN
-
144411-838 DECAL, WINDSCREEN - RIGHTDECAL, WINDSCREEN - RIGHT
-
144411-839 DECAL, WINDSCREEN - LEFTDECAL, WINDSCREEN - LEFT
