INTAKE ASSEMBLY для Arctic Cat Z 370 LX (GREEN) - 2005 года выпуска
-
№АртикулНазвание
-
13003-552 MANIFOLD, INTAKE (INC. 2)MANIFOLD, INTAKE (INC. 2)
-
23003-597 NOZZLE, OIL INJECTIONNOZZLE, OIL INJECTION
-
33004-334 NUTNUT
-
43004-280 WASHER, LOCKWASHER, LOCK
-
53004-301 BOLT, STUDBOLT, STUD
-
63003-503 GASKET, EXHAUSTGASKET, EXHAUST
-
73005-952 GASKET, INTAKEGASKET, INTAKE
-
83004-300 BOLT, STUDBOLT, STUD
-
93004-351 NUT W/WASHERNUT W/WASHER
-
103004-575 BOLT, STUDBOLT, STUD
-
113003-554 INSULATOR, INTAKE MANIFOLDINSULATOR, INTAKE MANIFOLD
-
123004-828 CAP, NOZZLECAP, NOZZLE
-
133008-037 CLAMPCLAMP
-
143423-204 WASHERWASHER
-
153004-279 BOLT, STUDBOLT, STUD
