SKI AND SPINDLE ASSEMBLY для Arctic Cat CROSSFIRE 600 EFI (BLACK) - 2007 года выпуска
-
№АртикулНазвание
-
12603-599 SKI, PLASTIC - BLACKSKI, PLASTIC - BLACK
-
22603-456 WEARBAR - RIGHTWEARBAR - RIGHT
-
22603-457 WEARBAR - LEFTWEARBAR - LEFT
-
38047-486 NUT, LOCKNUT, LOCK
-
40123-296 NUT, LOCKNUT, LOCK
-
50623-728 WASHERWASHER
-
62603-397 INSERT, SKIINSERT, SKI
-
70623-776 SCREW, CAPSCREW, CAP
-
80123-458 PIN, COTTERPIN, COTTER
-
92603-553 DAMPER, SKIDAMPER, SKI
-
101703-630 SPINDLE, STEERING - RIGHT - PLATINUM (INC. 11-18)SPINDLE, STEERING - RIGHT - PLATINUM (INC. 11-18)
-
101703-631 SPINDLE, STEERING - LEFT - PLATINUM (INC. 11-18)SPINDLE, STEERING - LEFT - PLATINUM (INC. 11-18)
-
110603-647 ...INSERT, SPINDLE...INSERT, SPINDLE
-
121623-010 ...FITTING, GREASE...FITTING, GREASE
-
130603-083 ...BEARING...BEARING
-
140603-158 ...BEARING...BEARING
-
151603-203 ...WASHER, THRUST...WASHER, THRUST
-
168005-584 ...SCREW, CAP...SCREW, CAP
-
171703-413 ...ARM, STEERING...ARM, STEERING
-
180623-796 ...RING, RETAINING...RING, RETAINING
-
190623-831 CAP, SPINDLECAP, SPINDLE
-
201603-908 SPACERSPACER
-
212603-548 AXLE, SPINDLEAXLE, SPINDLE
-
227611-060 DECAL, "AWS" - SPINDLE (GREEN)DECAL, "AWS" - SPINDLE (GREEN)
-
227611-254 DECAL, "AWS" - SPINDLE (BLACK) (ORANGE)DECAL, "AWS" - SPINDLE (BLACK) (ORANGE)
-
232603-598 HANDLE, PLASTIC - BLACKHANDLE, PLASTIC - BLACK
-
248047-366 NUT, LOCKNUT, LOCK
-
251623-689 SCREW, CAPSCREW, CAP
-
261623-688 SCREW, CAPSCREW, CAP
