OIL PUMP для Arctic Cat F5 EFI (ORANGE) - 2007 года выпуска
-
№АртикулНазвание
-
13007-470 PUMP, OIL W/90...FITTINGPUMP, OIL W/90...FITTING
-
23006-354 GEAR, DRIVEN - OIL PUMPGEAR, DRIVEN - OIL PUMP
-
33004-804 RETAINER, OIL PUMP INPUT SHAFTRETAINER, OIL PUMP INPUT SHAFT
-
43004-805 VALVE, CHECKVALVE, CHECK
-
53402-009 GASKETGASKET
-
63005-049 SHIM, OIL PUMP SHAFTSHIM, OIL PUMP SHAFT
-
73008-030 O-RINGO-RING
-
83005-126 O-RINGO-RING
-
93008-035 HOSE, OILHOSE, OIL
-
103005-357 HOSEHOSE
-
113004-346 BOLTBOLT
-
123008-037 CLAMP, HOSECLAMP, HOSE
-
133007-471 BOLTBOLT
-
143005-696 CLAMPCLAMP
-
153007-472 BRACKET, OIL PUMP CABLEBRACKET, OIL PUMP CABLE
