OIL TANK ASSEMBLY для Arctic Cat AC TZ1 PARK - 2009 года выпуска
-
№АртикулНазвание
-
10770-837 TANK, OIL - ASSEMBLY (INC. 2-8 AND TWO NO. 9)TANK, OIL - ASSEMBLY (INC. 2-8 AND TWO NO. 9)
-
21623-573 ...BUSHING, FLANGED...BUSHING, FLANGED
-
31670-729 ...GROMMET...GROMMET
-
41670-983 ...SCREEN, OIL TANK...SCREEN, OIL TANK
-
51670-914 ...PLUG, DRAIN (INC. 6)...PLUG, DRAIN (INC. 6)
-
61670-926 ......O-RING......O-RING
-
70610-641 ...HOSE, OIL - FEED...HOSE, OIL - FEED
-
80610-642 ...HOSE, OIL - RETURN...HOSE, OIL - RETURN
-
91623-515 ...CLAMP, HOSE...CLAMP, HOSE
-
100610-790 CONDUIT - 5 FTCONDUIT - 5 FT
-
110648-441 O-RINGO-RING
-
128408-616 SCREW, CAPSCREW, CAP
-
131670-727 FITTING, OIL SUPPLY - ENGINEFITTING, OIL SUPPLY - ENGINE
-
141670-726 FITTING, OIL RETURN - ENGINEFITTING, OIL RETURN - ENGINE
-
150610-664 HOSE, BREATHER - OIL TANKHOSE, BREATHER - OIL TANK
-
161623-288 CLAMP, HOSECLAMP, HOSE
-
171623-289 CLAMP, HOSECLAMP, HOSE
-
188476-630 SCREW, MACHINESCREW, MACHINE
-
191670-872 CAP, OIL TANK (INC. 20)CAP, OIL TANK (INC. 20)
-
201670-823 ...SEAL...SEAL
