WATER HOSE ASSEMBLY для Arctic Cat TZ1 LXR LTD - 2011 года выпуска
-
№АртикулНазвание
-
13007-182 THERMOSTATTHERMOSTAT
-
23003-924 CAP, THERMOSTAT (U.S.)CAP, THERMOSTAT (U.S.)
-
33007-369 SCREW, CAPSCREW, CAP
-
43007-513 HOSE, INLETHOSE, INLET
-
53007-184 HOSE, BYPASS - NO. 1HOSE, BYPASS - NO. 1
-
63007-514 HOSE, BYPASS - NO. 2HOSE, BYPASS - NO. 2
-
73007-186 HOSE, BYPASS - NO. 3HOSE, BYPASS - NO. 3
-
83007-187 FITTING, HOSEFITTING, HOSE
-
93007-188 CLAMP, HOSE - NO. 1CLAMP, HOSE - NO. 1
-
103004-923 CLAMP, HOSE - NO. 3CLAMP, HOSE - NO. 3
-
113008-488 CLAMP, HOSE - NO. 2CLAMP, HOSE - NO. 2
-
123007-857 CLAMP, HOSECLAMP, HOSE
-
133007-190 FITTING, HOSEFITTING, HOSE
-
143007-191 O-RINGO-RING
-
153007-515 SCREW, CAPSCREW, CAP
-
163007-516 CLIP, RETAININGCLIP, RETAINING
