IDLER WHEEL ASSEMBLY для Arctic Cat Z1 TURBO LXR (ORANGE) - 2011 года выпуска
-
№АртикулНазвание
-
18408-880 SCREW, CAPSCREW, CAP
-
28408-835 SCREW, CAPSCREW, CAP
-
33604-004 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
48427-802 NUT, LOCKNUT, LOCK
-
53604-486 WHEEL, IDLERWHEEL, IDLER
-
68450-133 WASHERWASHER
-
71423-064 SCREW, CAPSCREW, CAP
-
83604-083 SPACER, SHOCK - FRONT ARMSPACER, SHOCK - FRONT ARM
-
90623-912 WASHERWASHER
-
103604-269 AXLEAXLE
-
118427-002 NUT, LOCKNUT, LOCK
-
128408-850 SCREW, CAPSCREW, CAP
-
132604-516 SLIDE, SPRINGSLIDE, SPRING
-
143604-204 BLOCK, SLIDEBLOCK, SLIDE
-
151604-810 SPACER, REAR WHEELSPACER, REAR WHEEL
-
163604-300 AXLE, REARAXLE, REAR
-
173604-060 WHEEL, IDLER (INC. 18-19)WHEEL, IDLER (INC. 18-19)
-
183604-033 ...BEARING...BEARING
-
190623-946 ...RING, RETAINING...RING, RETAINING
-
202604-881 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
211704-490 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
228042-486 NUTNUT
-
230124-310 SCREW, CAPSCREW, CAP
-
243604-065 WHEEL, IDLER - ORANGE (INC. 18-19)WHEEL, IDLER - ORANGE (INC. 18-19)
-
250623-664 WASHERWASHER
-
268408-831 SCREW, CAPSCREW, CAP
-
271604-952 CAP, IDLER WHEELCAP, IDLER WHEEL
