WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat F 800 LXR (BLACK) - 2012 года выпуска
-
№АртикулНазвание
-
16606-313 POD, INSTRUMENTPOD, INSTRUMENT
-
20608-640 VENT, INTAKE - RIGHTVENT, INTAKE - RIGHT
-
20608-641 VENT, INTAKE - LEFTVENT, INTAKE - LEFT
-
31623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
40641-897 OUTLET, ACCESSORY - 12VOUTLET, ACCESSORY - 12V
-
50609-910 SWITCH, IGNITION (INC. 6-8)SWITCH, IGNITION (INC. 6-8)
-
60430-050 ...NUT, RETAINING...NUT, RETAINING
-
70430-042 ...KEY, IGNITION Y SERIES - LEFT-SIDE CUT...KEY, IGNITION Y SERIES - LEFT-SIDE CUT
-
70430-043 ...KEY, IGNITION Z SERIES - RIGHT-SIDE CUT...KEY, IGNITION Z SERIES - RIGHT-SIDE CUT
-
80430-054 ...COVER, KEY...COVER, KEY
-
90620-377 GAUGE, SPEEDOMETERGAUGE, SPEEDOMETER
-
106606-288 BRACKET, SPEEDOMETER GAUGE - CENTERBRACKET, SPEEDOMETER GAUGE - CENTER
-
110423-493 NUT W/WASHERNUT W/WASHER
-
128410-616 SCREW, CAPSCREW, CAP
-
136606-130 BRACKET, SPEEDOMETER GAUGE - RIGHTBRACKET, SPEEDOMETER GAUGE - RIGHT
-
136606-131 BRACKET, SPEEDOMETER GAUGE - LEFTBRACKET, SPEEDOMETER GAUGE - LEFT
-
148053-212 WASHER, EXTERNAL TOOTH LOCKWASHER, EXTERNAL TOOTH LOCK
-
158427-602 NUT, LOCKNUT, LOCK
-
160423-355 SCREW, SHOULDERSCREW, SHOULDER
-
171623-764 NUT, EXPANSIONNUT, EXPANSION
-
186606-377 WINDSHIELDWINDSHIELD
-
198477-516 SCREW, MACHINESCREW, MACHINE
