OIL TANK ASSEMBLY для Arctic Cat F 800 LXR (GREEN) - 2012 года выпуска
![](/wa-data/public/shop/sheme/arctic-cat/snow/df8fed20-27a9-45f1-901b-7ca8c572f3ed.gif)
-
№АртикулНазвание
-
11670-365 CAP, OIL TANK (INC. 2)CAP, OIL TANK (INC. 2)
-
20109-733 ...SEAL, CAP - OIL TANK...SEAL, CAP - OIL TANK
-
31623-969 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
40621-502 DECAL, OIL LEVELDECAL, OIL LEVEL
-
52670-225 NECK, OIL FILLNECK, OIL FILL
-
61623-972 O-RINGO-RING
-
71623-814 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
82670-257 GLASS, SIGHTGLASS, SIGHT
-
90770-964 TANK, OILTANK, OIL
-
100609-915 SENSOR, LOW OILSENSOR, LOW OIL
-
110648-441 O-RINGO-RING
-
122670-229 FITTING, OUTLETFITTING, OUTLET
-
131623-042 CLAMP, HOSECLAMP, HOSE
-
140610-692 HOSE - GREEN - 25 FTHOSE - GREEN - 25 FT
-
140610-693 HOSE - GREEN - 100 FTHOSE - GREEN - 100 FT
-
151619-345 CONDUIT, FLEXIBLE - 3 FTCONDUIT, FLEXIBLE - 3 FT
-
161048-063 SEALANT - 70 MLSEALANT - 70 ML
