FRONT SUSPENSION SHOCK ABSORBER для Arctic Cat M 800 HCR - 2012 года выпуска
-
№АртикулНазвание
-
-2703-870 COMPLETE SHOCK ABSORBER - RIGHTCOMPLETE SHOCK ABSORBER - RIGHT
-
-2703-871 COMPLETE SHOCK ABSORBER - LEFTCOMPLETE SHOCK ABSORBER - LEFT
-
11604-222 BUSHINGBUSHING
-
22604-223 SLEEVESLEEVE
-
33604-652 KIT, SEAL/BEARING REBUILD (INC. 4-6)KIT, SEAL/BEARING REBUILD (INC. 4-6)
-
40603-301 ...NUT...NUT
-
51604-428 ...PLUG, RUBBER - VALVE...PLUG, RUBBER - VALVE
-
62603-337 ...BALL, AIR VALVE...BALL, AIR VALVE
-
72603-963 END CAP, SHOCK - RIGHT ASSEMBLY (INC. 8-13)END CAP, SHOCK - RIGHT ASSEMBLY (INC. 8-13)
-
72603-962 END CAP, SHOCK - LEFT ASSEMBLY (INC. 8-13)END CAP, SHOCK - LEFT ASSEMBLY (INC. 8-13)
-
82603-511 ...VALVE, AIR...VALVE, AIR
-
92603-965 ...SEAL...SEAL
-
102603-980 ...CAP, AIR VALVE...CAP, AIR VALVE
-
113604-653 ...PISTON, INTERNAL FLOATING...PISTON, INTERNAL FLOATING
-
122603-967 ...RESERVIOR...RESERVIOR
-
132603-966 ...END CAP, RESERVIOR...END CAP, RESERVIOR
-
142603-981 DECAL, RESERVOIRDECAL, RESERVOIR
-
152603-411 BODY, SHOCK - UPPERBODY, SHOCK - UPPER
-
162603-982 DECAL, SHOCKDECAL, SHOCK
-
172603-906 BEARING - ASSEMBLYBEARING - ASSEMBLY
-
181604-315 BALL, BLEEDBALL, BLEED
-
191603-940 SCREW, SETSCREW, SET
-
202603-954 ROD, SHOCKROD, SHOCK
-
212603-522 GUIDE, SPRINGGUIDE, SPRING
-
222603-656 SPRINGSPRING
-
230603-540 WASHER, TOP OUTWASHER, TOP OUT
-
240603-334 VALVE, 0.800 X 0.008 IN.VALVE, 0.800 X 0.008 IN.
-
250603-337 VALVE, 0.900 X 0.008 IN.VALVE, 0.900 X 0.008 IN.
-
260603-340 VALVE, 1.000 X 0.008 IN.VALVE, 1.000 X 0.008 IN.
-
270603-343 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
280603-347 VALVE, 1.250 X 0.010 IN.VALVE, 1.250 X 0.010 IN.
-
290603-349 VALVE, 1.300 X 0.008 IN.VALVE, 1.300 X 0.008 IN.
-
300603-335 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
310603-342 VALVE, 1.100 X 0.006 IN.VALVE, 1.100 X 0.006 IN.
-
322603-936 VALVE, RING - 1.250 X 0.008 IN.VALVE, RING - 1.250 X 0.008 IN.
-
330603-348 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
342603-934 PISTON, 0.081 IN. - ORIFICEPISTON, 0.081 IN. - ORIFICE
-
350603-882 VALVE, 1.100 X 0.012 IN.VALVE, 1.100 X 0.012 IN.
-
360603-341 VALVE, 1.000 X 0.010 IN.VALVE, 1.000 X 0.010 IN.
-
370603-330 VALVE, 0.700 X 0.006 IN.VALVE, 0.700 X 0.006 IN.
-
382603-902 VALVE, 0.550 X 0.020 IN.VALVE, 0.550 X 0.020 IN.
-
390603-389 WASHER, BACKUPWASHER, BACKUP
-
402603-919 PISTON, FLOATING W/O-RINGPISTON, FLOATING W/O-RING
-
412603-955 BODY, SHOCK - LOWERBODY, SHOCK - LOWER
-
422603-338 SCREW, SETSCREW, SET
-
434639-012 FLUID, FLOAT SHOCK - 8 OZFLUID, FLOAT SHOCK - 8 OZ
-
445639-240 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
