OIL TANK ASSEMBLY для Arctic Cat XF 1100 TURBO SNO PRO LTD (INTERNATIONAL) - 2012 года выпуска
-
№АртикулНазвание
-
12670-224 CAP, OIL TANK (INC. 2)CAP, OIL TANK (INC. 2)
-
22670-135 ...SEAL, CAP - OIL TANK...SEAL, CAP - OIL TANK
-
31623-969 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
42670-218 FITTING, ELBOWFITTING, ELBOW
-
50670-183 O-RINGO-RING
-
61623-814 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
72670-257 GLASS, SIGHTGLASS, SIGHT
-
80770-963 TANK, OILTANK, OIL
-
92670-219 TUBE, OIL TANKTUBE, OIL TANK
-
101602-213 O-RINGO-RING
-
112602-099 PLUG, DRAINPLUG, DRAIN
-
120673-459 O-RINGO-RING
-
132670-222 SCREEN, OIL TANKSCREEN, OIL TANK
-
142670-290 O-RINGO-RING
-
152670-220 FITTING, OIL SUPPLY - ENGINEFITTING, OIL SUPPLY - ENGINE
-
162670-221 FITTING, OIL RETURN - ENGINEFITTING, OIL RETURN - ENGINE
-
170610-840 HOSEHOSE
-
181623-230 CLAMP, HOSECLAMP, HOSE
-
192670-226 TUBE, OIL RETURNTUBE, OIL RETURN
-
202670-170 FITTING, OIL RETURN - ENGINEFITTING, OIL RETURN - ENGINE
-
210648-441 O-RINGO-RING
-
228408-616 SCREW, CAPSCREW, CAP
-
232670-169 FITTING, OIL SUPPLY - ENGINEFITTING, OIL SUPPLY - ENGINE
-
240610-839 HOSE, OIL FEEDHOSE, OIL FEED
-
252670-227 TUBE, OIL FEEDTUBE, OIL FEED
-
260610-869 HOSE, BREATHER - UPPERHOSE, BREATHER - UPPER
-
271623-288 CLAMP, HOSECLAMP, HOSE
-
282670-267 TUBE, BREATHERTUBE, BREATHER
-
291623-958 GROMMETGROMMET
-
300610-844 HOSE, BREATHER - OIL TANKHOSE, BREATHER - OIL TANK
-
311623-292 CLAMP, HOSECLAMP, HOSE
-
320610-880 HOSE, BREATHER - OIL SEPARATOR/AIR FILTERHOSE, BREATHER - OIL SEPARATOR/AIR FILTER
-
332670-324 FITTING, ELBOWFITTING, ELBOW
-
341619-486 CONDUIT, FLEXIBLE - 5 FTCONDUIT, FLEXIBLE - 5 FT
-
350610-843 HOSE, BREATHER - OIL SEPARATORHOSE, BREATHER - OIL SEPARATOR
-
361048-063 SEALANT - 70 MLSEALANT - 70 ML
-
372670-406 O-RINGO-RING
