BATTERY AND TRAY ASSEMBLY для Arctic Cat TZ1 Turbo LXR [S2013TZNTXUSB] - 2013 года выпуска
-
№АртикулНазвание
-
10645-480 BATTERY (INC. 2)BATTERY (INC. 2)
-
20645-430 ...DECAL, WARNING...DECAL, WARNING
-
30745-348 TRAY, BATTERYTRAY, BATTERY
-
48408-630 SCREW, CAPSCREW, CAP
-
51623-984 CLAMP, ROUTINGCLAMP, ROUTING
-
68427-602 NUT, LOCKNUT, LOCK
-
70745-317 BRACKET, HOLD-DOWN - BATTERYBRACKET, HOLD-DOWN - BATTERY
-
81623-725 SCREW, SHOULDERSCREW, SHOULDER
-
90745-329 ROD, HOLD-DOWN - BATTERYROD, HOLD-DOWN - BATTERY
-
108050-217 WASHERWASHER
-
110423-716 NUT, WINGNUT, WING
-
128427-802 NUT, LOCKNUT, LOCK
-
138476-816 SCREW, MACHINESCREW, MACHINE
-
140123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
150445-092 SOLENOID, STARTER RELAYSOLENOID, STARTER RELAY
-
160623-038 NUT W/WASHERNUT W/WASHER
-
170645-587 CABLE, BATTERY/SOLENOID (INC. 18)CABLE, BATTERY/SOLENOID (INC. 18)
-
180645-521 ...BOOT, TERMINAL - BATTERY...BOOT, TERMINAL - BATTERY
-
190645-586 CABLE, BATTERY/GROUNDCABLE, BATTERY/GROUND
-
200645-590 CABLE, STARTER-TO-GROUNDCABLE, STARTER-TO-GROUND
-
210645-589 CABLE, SOLENOID/STARTER (INC. 22)CABLE, SOLENOID/STARTER (INC. 22)
-
220645-581 ...BOOT, TERMINAL...BOOT, TERMINAL
-
231623-451 SCREW, CAP W/WASHERSCREW, CAP W/WASHER
