HOOD AND AIR INTAKE ASSEMBLY для Arctic Cat XF 1100 LXR - GREEN [S2013XFNLXUSG] - 2013 года выпуска
-
№АртикулНазвание
-
13718-540 HOOD W/DECALS - RIGHT - BLACK (INC. 2-4)HOOD W/DECALS - RIGHT - BLACK (INC. 2-4)
-
13718-541 HOOD W/DECALS - LEFT - BLACK (INC. 2-4)HOOD W/DECALS - LEFT - BLACK (INC. 2-4)
-
23718-486 ...HOOD W/O DECALS - RIGHT - BLACK (INC. 3)...HOOD W/O DECALS - RIGHT - BLACK (INC. 3)
-
23718-313 ...HOOD W/O DECALS - LEFT - BLACK (INC. 3)...HOOD W/O DECALS - LEFT - BLACK (INC. 3)
-
36606-420 ......FOIL, PROTECTIVE - RIGHT......FOIL, PROTECTIVE - RIGHT
-
36606-415 ......FOIL, PROTECTIVE - LEFT......FOIL, PROTECTIVE - LEFT
-
49611-984 ...DECAL, HOOD - RIGHT - GREEN...DECAL, HOOD - RIGHT - GREEN
-
49611-985 ...DECAL, HOOD - LEFT - GREEN...DECAL, HOOD - LEFT - GREEN
-
50623-784 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
66606-383 PLENUM, INTAKE - UPPERPLENUM, INTAKE - UPPER
-
79611-752 DECAL, "ARCTIC CAT"DECAL, "ARCTIC CAT"
-
80608-696 SCREEN, VENTSCREEN, VENT
-
96606-386 BOOT, INTAKEBOOT, INTAKE
-
101623-933 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
110623-797 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
121623-939 CLIP, U-NUTCLIP, U-NUT
-
131623-929 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
141623-637 CLIP, U-NUTCLIP, U-NUT
-
155706-357 PLENUM, INTAKE - LOWER FRONT (INC. 16)PLENUM, INTAKE - LOWER FRONT (INC. 16)
-
169611-835 ...DECAL, REFLECTOR - AMBER...DECAL, REFLECTOR - AMBER
-
176606-421 FOIL, PROTECTIVEFOIL, PROTECTIVE
-
185706-372 PLENUM, INTAKE - LOWER REAR (INC. 19)PLENUM, INTAKE - LOWER REAR (INC. 19)
-
196606-419 ...FOIL, PROTECTIVE...FOIL, PROTECTIVE
-
200617-644 SEALSEAL
-
212670-164 DUCT, INTAKEDUCT, INTAKE
-
220423-018 CLAMPCLAMP
-
232670-161 BOOT, THROTTLE BODYBOOT, THROTTLE BODY
-
240406-877 BUMPERBUMPER
-
252670-160 SILENCER, AIR - ASSEMBLY (INC. 26-27)SILENCER, AIR - ASSEMBLY (INC. 26-27)
-
262670-183 ...BAFFLE, AIR SILENCER...BAFFLE, AIR SILENCER
-
271623-251 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
281623-291 CLAMP, HOSECLAMP, HOSE
-
290610-852 HOSE, BREATHERHOSE, BREATHER
