REAR SUSPENSION FRONT ARM SHOCK ABSORBER для Arctic Cat XF 800 Sno Pro - High Country LTD (WHITE) [S2013XFHHCOSW] (INTERNATIONAL) - 2013 года выпуска
-
№АртикулНазвание
-
-2704-325 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
10604-625 EYELET, SHOCKEYELET, SHOCK
-
22604-883 ROD, SHOCKROD, SHOCK
-
32604-812 BEARING - ASSEMBLYBEARING - ASSEMBLY
-
42604-815 KIT, SEAL/REBUILDKIT, SEAL/REBUILD
-
50603-540 WASHER, TOP OUTWASHER, TOP OUT
-
60603-339 VALVE, 1.000 X 0.006 IN.VALVE, 1.000 X 0.006 IN.
-
70603-340 VALVE, 1.000 X 0.008 IN.VALVE, 1.000 X 0.008 IN.
-
80603-344 VALVE, 1.100 X 0.010 IN.VALVE, 1.100 X 0.010 IN.
-
90603-347 VALVE, 1.250 X 0.010 IN.VALVE, 1.250 X 0.010 IN.
-
100603-349 VALVE, 1.300 X 0.008 IN.VALVE, 1.300 X 0.008 IN.
-
110603-337 VALVE, 0.900 X 0.008 IN.VALVE, 0.900 X 0.008 IN.
-
120603-348 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
133604-509 PISTON, 0.063 IN. - ORIFICEPISTON, 0.063 IN. - ORIFICE
-
140603-343 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
150603-334 VALVE, 0.800 X 0.008 IN.VALVE, 0.800 X 0.008 IN.
-
160603-331 VALVE, 0.700 X 0.008 IN.VALVE, 0.700 X 0.008 IN.
-
172603-902 VALVE, 0.550 X 0.020 IN.VALVE, 0.550 X 0.020 IN.
-
180603-389 WASHER, BACKUPWASHER, BACKUP
-
190603-301 NUTNUT
-
202604-816 PISTON, FLOATINGPISTON, FLOATING
-
211604-316 SCREW, MACHINE W/O-RING (INC. 22)SCREW, MACHINE W/O-RING (INC. 22)
-
221604-425 ...O-RING...O-RING
-
232603-245 RETAINER, WEAR SLEEVERETAINER, WEAR SLEEVE
-
242603-246 SLEEVE, WEARSLEEVE, WEAR
-
252604-840 NUT, ADJUSTERNUT, ADJUSTER
-
262604-841 COLLAR, LOCKING - ADJUSTER NUTCOLLAR, LOCKING - ADJUSTER NUT
-
272603-475 DECAL, SHOCKDECAL, SHOCK
-
283604-178 BODY, SHOCKBODY, SHOCK
-
292604-817 END CAP, SHOCK - ASSEMBLY (INC. 30-31)END CAP, SHOCK - ASSEMBLY (INC. 30-31)
-
300703-341 ...VALVE, PRESSURE - ASSEMBLY (INC. 31)...VALVE, PRESSURE - ASSEMBLY (INC. 31)
-
311604-318 ......O-RING......O-RING
-
320624-097 SCREW, VALVESCREW, VALVE
-
332604-415 SLEEVESLEEVE
-
345639-240 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
