CHAIN CASE ASSEMBLY для Arctic Cat XF 8000 LXR - BLACK [S2014XFHLXUSB] - 2014 года выпуска
-
№АртикулНазвание
-
11702-348 CHAIN CASE ASSEMBLY (INC. 2-10)CHAIN CASE ASSEMBLY (INC. 2-10)
-
22602-172 ...SEAL...SEAL
-
32602-281 ...BEARING...BEARING
-
42602-280 ...RING, RETAINING...RING, RETAINING
-
52602-204 ...SEAL...SEAL
-
62602-368 ...SPACER...SPACER
-
72602-205 ...BEARING...BEARING
-
82602-236 ...RING, RETAINING...RING, RETAINING
-
92602-290 ...SLEEVE, ADAPTER...SLEEVE, ADAPTER
-
102602-641 ...FITTING, ELBOW...FITTING, ELBOW
-
110623-118 WASHER, SHIM (.030 IN.)WASHER, SHIM (.030 IN.)
-
110623-119 WASHER, SHIM (.075 IN.)WASHER, SHIM (.075 IN.)
-
122602-239 RING, RETAININGRING, RETAINING
-
132602-335 SPROCKET - 22T (13 WIDE)SPROCKET - 22T (13 WIDE)
-
141623-038 WASHER, SPRINGWASHER, SPRING
-
158408-826 SCREW, CAPSCREW, CAP
-
162602-364 SPROCKET - 48T (13 WIDE)SPROCKET - 48T (13 WIDE)
-
172602-370 CHAIN - 90P (13 WIDE)CHAIN - 90P (13 WIDE)
-
182602-473 RING, RETAININGRING, RETAINING
-
191702-319 ARM, TENSIONER - ASSEMBLYARM, TENSIONER - ASSEMBLY
-
202602-336 SPRINGSPRING
-
212602-230 PLATE, RATCHETPLATE, RATCHET
-
228427-602 NUT, LOCKNUT, LOCK
-
238476-630 SCREW, MACHINESCREW, MACHINE
-
248468-622 SCREW, MACHINESCREW, MACHINE
-
252602-208 SEAL, CHAIN CASESEAL, CHAIN CASE
-
261702-178 COVER, CHAIN CASE (INC. 27-28)COVER, CHAIN CASE (INC. 27-28)
-
272602-232 ...GLASS, SIGHT...GLASS, SIGHT
-
280730-172 ...KIT, SPEEDOMETER SENSOR...KIT, SPEEDOMETER SENSOR
-
298468-626 SCREW, MACHINESCREW, MACHINE
-
301623-984 CLAMP, ROUTINGCLAMP, ROUTING
-
312602-440 PLUG, FILLPLUG, FILL
