WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat XF 6000 CROSS-COUNTRY 141 (INTERNATIONAL) (ORANGE) [S2015X6DCCOSO] - 2015 года выпуска
-
№АртикулНазвание
-
14718-258 POD W/DECALS - WHITE (INC. 2-3)POD W/DECALS - WHITE (INC. 2-3)
-
26606-316 ...POD, INSTRUMENT - WHITE...POD, INSTRUMENT - WHITE
-
31621-438 ...DECAL, POD - RIGHT...DECAL, POD - RIGHT
-
31621-439 DECAL, POD - LEFTDECAL, POD - LEFT
-
40641-897 OUTLET, ACCESSORY - 12VOUTLET, ACCESSORY - 12V
-
51623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
60608-736 SCREEN, INTAKE - INJECTION MOLD - RIGHTSCREEN, INTAKE - INJECTION MOLD - RIGHT
-
60608-737 SCREEN, INTAKE - INJECTION MOLD - LEFTSCREEN, INTAKE - INJECTION MOLD - LEFT
-
76606-556 VENTVENT
-
80609-910 SWITCH, IGNITION (INC. 9-11)SWITCH, IGNITION (INC. 9-11)
-
90430-050 ...NUT, FLANGE - IGNITION SWITCH...NUT, FLANGE - IGNITION SWITCH
-
100430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
-
100430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
-
110430-054 ...COVER, KEY...COVER, KEY
-
120720-031 GAUGE, SPEEDOMETERGAUGE, SPEEDOMETER
-
136606-714 BRACKET, SPEEDOMETER GAUGE - CENTERBRACKET, SPEEDOMETER GAUGE - CENTER
-
148427-602 NUT, LOCKNUT, LOCK
-
158053-212 WASHER, LOCKWASHER, LOCK
-
168410-616 SCREW, CAPSCREW, CAP
-
176606-130 BRACKET, SPEEDOMETER GAUGE - RIGHTBRACKET, SPEEDOMETER GAUGE - RIGHT
-
176606-131 BRACKET, SPEEDOMETER GAUGE - LEFTBRACKET, SPEEDOMETER GAUGE - LEFT
-
180423-355 SCREW, SHOULDERSCREW, SHOULDER
-
191623-764 NUT, EXPANSIONNUT, EXPANSION
-
206606-482 WINDSHIELD - LOW - ORANGEWINDSHIELD - LOW - ORANGE
-
218477-516 SCREW, MACHINESCREW, MACHINE
