DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES для Arctic Cat XF 7000 LXR 137 (GREEN) [S2015XFULXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
10728-225 TRACK, DRIVE - ASSEMBLY (INC. 2-8)TRACK, DRIVE - ASSEMBLY (INC. 2-8)
-
21702-243 ...PLUG, MAGNETIC - ASSEMBLY (INC. 3)...PLUG, MAGNETIC - ASSEMBLY (INC. 3)
-
32602-211 ......MAGNET,.250 X .250......MAGNET,.250 X .250
-
42602-740 ...DRIVESHAFT...DRIVESHAFT
-
52602-771 ...SPROCKET, DRIVE...SPROCKET, DRIVE
-
61702-206 ...PLATE, RETAINING - SEAL (INC. 7)...PLATE, RETAINING - SEAL (INC. 7)
-
71602-344 ......SEAL,OIL-45MM X 65MM X 8MM......SEAL,OIL-45MM X 65MM X 8MM
-
82602-233 ...SNAP RING(FS-0175)...SNAP RING(FS-0175)
-
98408-831 SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353
-
102602-486 CALIPER, BRAKE - ASSEMBLY (INC. 11-18)CALIPER, BRAKE - ASSEMBLY (INC. 11-18)
-
112602-411 ...SEAL,CROSSOVER...SEAL,CROSSOVER
-
122602-198 ...BEARING (6009-2RSFP-C3)...BEARING (6009-2RSFP-C3)
-
132602-280 ...RING,SNAP(EH-75)...RING,SNAP(EH-75)
-
142602-410 ...PISTON SET...PISTON SET
-
151702-245 ...PAD, BRAKE - SET (INC. 16)...PAD, BRAKE - SET (INC. 16)
-
162602-409 ......PIN, RETAINING......PIN, RETAINING
-
172602-408 ...FITTING,BLEEDER...FITTING,BLEEDER
-
182602-412 ...BOLT,BRAKE CALIPER...BOLT,BRAKE CALIPER
-
192602-249 DISK,BRAKE-FORGED-34T SPLINED-BOTTOMDISK,BRAKE-FORGED-34T SPLINED-BOTTOM
-
202602-629 SNAP RING-(MSH-43)SNAP RING-(MSH-43)
-
211702-370 SHAFT, DRIVEN - ASSEMBLY (INC. 22-25)SHAFT, DRIVEN - ASSEMBLY (INC. 22-25)
-
222602-772 ...SHAFT, DRIVEN...SHAFT, DRIVEN
-
231707-585 ...SUPPORT, CHASSIS - LEFT...SUPPORT, CHASSIS - LEFT
-
242602-524 ...BEARING,30 X 62 X 16-6206 2RLD-C3...BEARING,30 X 62 X 16-6206 2RLD-C3
-
252602-729 ...SNAP RING (FH-062)...SNAP RING (FH-062)
-
260648-839 SPACER-30IDX38ODX7.62SPACER-30IDX38ODX7.62
-
270648-816 WASHER, SHIM (.030 IN.)WASHER, SHIM (.030 IN.)
-
270648-817 WASHER, SHIM (.060 IN.)WASHER, SHIM (.060 IN.)
-
270648-818 WASHER, SHIM (.090 IN.)WASHER, SHIM (.090 IN.)
-
280726-339 CLUTCH, DRIVEN - ASSEMBLYCLUTCH, DRIVEN - ASSEMBLY
-
290648-441 O-RING,ADJUSTER SHEAVE (2-121)O-RING,ADJUSTER SHEAVE (2-121)
-
300648-715 WASHER, SHIM (.030 IN.)WASHER, SHIM (.030 IN.)
-
300648-716 WASHER, SHIM (.060 IN.)WASHER, SHIM (.060 IN.)
-
300648-714 WASHER, SHIM (.090 IN.)WASHER, SHIM (.090 IN.)
-
311702-114 KIT,ADJUSTER-SHEAVE W/WASHER (INC. 32)KIT,ADJUSTER-SHEAVE W/WASHER (INC. 32)
-
320648-788 ...WASHER,THRUST-DRIVEN ADJUSTER...WASHER,THRUST-DRIVEN ADJUSTER
-
338450-127 WASHER,FLAT-M8-9.12 X 18.80 X 2.30Z & YWASHER,FLAT-M8-9.12 X 18.80 X 2.30Z & Y
-
348051-242 WASHER,SPR LOCK-5/16 .314X.583X.078 Z & YWASHER,SPR LOCK-5/16 .314X.583X.078 Z & Y
-
358408-801 SCREW,CAP-HFH M8X1.25X100 CL8.8Z & Y/W2353SCREW,CAP-HFH M8X1.25X100 CL8.8Z & Y/W2353
