CAMSHAFT- CHAIN- AND VALVE ASSEMBLY для Arctic Cat XF 7000 SNO PRO CROSS-COUNTRY 141 (INTERNATIONAL) (ORANGE) [S2015X7UCCOSO] - 2015 года выпуска
-
№АртикулНазвание
-
13020-236 VALVE, INTAKEVALVE, INTAKE
-
23020-237 SEAT, SPRINGSEAT, SPRING
-
33020-238 SEALSEAL
-
43020-239 SPRING, VALVESPRING, VALVE
-
53020-240 RETAINER, SPRINGRETAINER, SPRING
-
63020-241 COTTER, VALVECOTTER, VALVE
-
73020-242 SHIM, TAPPET - (1.20 MM)SHIM, TAPPET - (1.20 MM)
-
73020-243 SHIM, TAPPET - (1.25 MM)SHIM, TAPPET - (1.25 MM)
-
73020-244 SHIM, TAPPET - (1.30 MM)SHIM, TAPPET - (1.30 MM)
-
73020-245 SHIM, TAPPET - (1.35 MM)SHIM, TAPPET - (1.35 MM)
-
73020-246 SHIM, TAPPET - (1.40 MM)SHIM, TAPPET - (1.40 MM)
-
73020-247 SHIM, TAPPET - (1.45 MM)SHIM, TAPPET - (1.45 MM)
-
73020-248 SHIM, TAPPET - (1.50 MM)SHIM, TAPPET - (1.50 MM)
-
73020-249 SHIM, TAPPET - (1.55 MM)SHIM, TAPPET - (1.55 MM)
-
73020-250 SHIM, TAPPET - (1.60 MM)SHIM, TAPPET - (1.60 MM)
-
73020-251 SHIM, TAPPET - (1.65 MM)SHIM, TAPPET - (1.65 MM)
-
73020-252 SHIM, TAPPET - (1.70 MM)SHIM, TAPPET - (1.70 MM)
-
73020-253 SHIM, TAPPET - (1.75 MM)SHIM, TAPPET - (1.75 MM)
-
73020-254 SHIM, TAPPET - (1.80 MM)SHIM, TAPPET - (1.80 MM)
-
73020-255 SHIM, TAPPET - (1.85 MM)SHIM, TAPPET - (1.85 MM)
-
73020-256 SHIM, TAPPET - (1.90 MM)SHIM, TAPPET - (1.90 MM)
-
73020-257 SHIM, TAPPET - (1.95 MM)SHIM, TAPPET - (1.95 MM)
-
73020-258 SHIM, TAPPET - (2.00 MM)SHIM, TAPPET - (2.00 MM)
-
73020-259 SHIM, TAPPET - (2.05 MM)SHIM, TAPPET - (2.05 MM)
-
73020-260 SHIM, TAPPET - (2.10 MM)SHIM, TAPPET - (2.10 MM)
-
73020-261 SHIM, TAPPET - (2.15 MM)SHIM, TAPPET - (2.15 MM)
-
73020-262 SHIM, TAPPET - (2.20 MM)SHIM, TAPPET - (2.20 MM)
-
73020-263 SHIM, TAPPET - (2.25 MM)SHIM, TAPPET - (2.25 MM)
-
73020-264 SHIM, TAPPET - (2.30 MM)SHIM, TAPPET - (2.30 MM)
-
73020-265 SHIM, TAPPET - (2.35 MM)SHIM, TAPPET - (2.35 MM)
-
73020-266 SHIM, TAPPET - (2.40 MM)SHIM, TAPPET - (2.40 MM)
-
83020-267 TAPPET - (YELLOW)TAPPET - (YELLOW)
-
83020-268 TAPPET - (GREEN)TAPPET - (GREEN)
-
93020-269 VALVE, EXHAUSTVALVE, EXHAUST
-
103020-270 CAMSHAFT, INTAKECAMSHAFT, INTAKE
-
113020-271 CAMSHAFT, EXHAUSTCAMSHAFT, EXHAUST
-
123020-272 SPROCKETSPROCKET
-
133020-273 SCREW, CAPSCREW, CAP
-
143020-274 CHAIN, CAMCHAIN, CAM
-
153020-275 GUIDE, CAM CHAINGUIDE, CAM CHAIN
-
163020-276 SCREW, SHOULDERSCREW, SHOULDER
-
173020-277 TENSIONER, CAM CHAINTENSIONER, CAM CHAIN
-
183020-278 GASKETGASKET
-
193020-279 ADJUSTER, TENSIONER - ASSEMBLYADJUSTER, TENSIONER - ASSEMBLY
-
203020-280 SCREW, CAPSCREW, CAP
