IDLER WHEEL ASSEMBLY для Arctic Cat XF 8000 LXR (GREEN) [S2015XFHLXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
11423-064 SCREW, CAPSCREW, CAP
-
23604-083 SPACERSPACER
-
30623-912 WASHER, FLAT - 0.890 X 1.19 X 0.060 Z & YWASHER, FLAT - 0.890 X 1.19 X 0.060 Z & Y
-
43604-269 AXLEAXLE
-
51623-992 WASHER, INTERNAL TOOTH LOCKWASHER, INTERNAL TOOTH LOCK
-
68422-002 NUT, LOCKNUT, LOCK
-
78413-620 SCREW, CAPSCREW, CAP
-
83604-899 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
98422-602 NUT, LOCKNUT, LOCK
-
108413-675 SCREW, CAPSCREW, CAP
-
113604-039 WHEEL, IDLER (INC. 12-13)WHEEL, IDLER (INC. 12-13)
-
123604-033 ...BEARING...BEARING
-
130623-946 ...RING, RETAINING...RING, RETAINING
-
142623-025 WASHERWASHER
-
158427-602 NUT, HEX FLG-NYL LOCK M6X1.0 CL8 Z & YNUT, HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
-
168427-802 NUT, HEX FLG-NYL LOCK M8X1.25 CL8 Z & YNUT, HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
-
173604-204 BLOCK, SLIDEBLOCK, SLIDE
-
182604-515 SLIDE, SPRINGSLIDE, SPRING
-
198450-133 WASHER, FLATWASHER, FLAT
-
208408-855 SCREW, CAPSCREW, CAP
-
213604-327 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
221623-794 WASHER, FLATWASHER, FLAT
-
231704-674 PIVOT, SHOCK (INC. 24)PIVOT, SHOCK (INC. 24)
-
241623-010 ...FITTING, GREASE...FITTING, GREASE
-
253604-325 SPACERSPACER
-
263604-285 AXLEAXLE
-
278413-031 SCREW, CAPSCREW, CAP
-
281623-931 WASHER, FLATWASHER, FLAT
-
293604-641 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
304604-137 WHEEL, IDLER - TRI-HUB - 8.00 W/0.787 IDWHEEL, IDLER - TRI-HUB - 8.00 W/0.787 ID
-
313604-640 AXLE, REARAXLE, REAR
-
328408-620 SCREW, CAPSCREW, CAP
-
333604-647 ADJUSTER, TRACKADJUSTER, TRACK
-
348422-802 NUT, LOCKNUT, LOCK
-
351623-682 SCREW, CAPSCREW, CAP
