HANDLEBAR AND CONTROLS для Arctic Cat ZR 8000 LXR (GREEN) [S2015ZRHLXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
11705-092 HANDLEBAR - (BLACK)HANDLEBAR - (BLACK)
-
24606-945 GRIP - (6.25 IN.)GRIP - (6.25 IN.)
-
30609-888 CONTROL, THROTTLE - RIGHT HAND - REAR (36 MM) (INC. 4-9)CONTROL, THROTTLE - RIGHT HAND - REAR (36 MM) (INC. 4-9)
-
40609-859 ...KIT, THROTTLE LEVER MOUNTING (INC. 5-8)...KIT, THROTTLE LEVER MOUNTING (INC. 5-8)
-
80123-766 ......NUT, PUSH (INCLUDED IN KIT)......NUT, PUSH (INCLUDED IN KIT)
-
90609-797 ...LEVER, THROTTLE - (36MM)...LEVER, THROTTLE - (36MM)
-
100617-248 PAD, INSULATOR - THUMB WARMERPAD, INSULATOR - THUMB WARMER
-
110609-827 ELEMENT, THUMB WARMER - HI/LO (15 V)ELEMENT, THUMB WARMER - HI/LO (15 V)
-
120609-595 CLIP, RETAININGCLIP, RETAINING
-
130609-880 CONTROL, RIGHT HAND - FRONT W/REVERSE - 2-STROKE (2010)CONTROL, RIGHT HAND - FRONT W/REVERSE - 2-STROKE (2010)
-
140609-792 COVER, CONNECTORCOVER, CONNECTOR
-
150609-793 SCREW, MACHINESCREW, MACHINE
-
160609-791 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
170687-223 CABLE, THROTTLECABLE, THROTTLE
-
180609-938 ELEMENT, HANDWARMER - RIGHTELEMENT, HANDWARMER - RIGHT
-
180609-939 ELEMENT, HANDWARMER - LEFTELEMENT, HANDWARMER - LEFT
-
190609-929 CONTROL, LEFT HAND W/O PPT - FRONTCONTROL, LEFT HAND W/O PPT - FRONT
-
200609-883 CONTROL, LEFT HAND - REARCONTROL, LEFT HAND - REAR
-
211686-636 HARNESS, HANDLEBAR - 2 STROKEHARNESS, HANDLEBAR - 2 STROKE
-
226606-129 PAD, HANDLEBARPAD, HANDLEBAR
-
230123-811 TIE, CABLE - (4 IN.)TIE, CABLE - (4 IN.)
-
230123-788 TIE, CABLE - (8 IN.)TIE, CABLE - (8 IN.)
