SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat M 8000 LTD 162 BLACK [S2016M8HPEUSB] - 2016 года выпуска

№

Артикул

Название
1

4718-654 PANEL, SIDE - W/DECALS - RIGHT - BLACK (INC. 2-7, 13-15, 17, AND 18)

PANEL, SIDE - W/DECALS - RIGHT - BLACK (INC. 2-7, 13-15, 17, AND 18)

55 320 ₽
2

3718-180 ...PANEL, SIDE - W/O DECALS - RIGHT - BLACK (INC. 3-7, 17, AND 20)

...PANEL, SIDE - W/O DECALS - RIGHT - BLACK (INC. 3-7, 17, AND 20)

39 930 ₽
3

0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

650 ₽
4

6606-414 ......FOIL, PROTECTIVE

......FOIL, PROTECTIVE

290 ₽
5

0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT

......FOAM, SIDE PANEL - UPPER REAR - RIGHT

5 400 ₽
6

0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

3 320 ₽
7

0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT

......FOAM, SIDE PANEL - LOWER REAR - RIGHT

5 820 ₽
8

4718-655 PANEL, SIDE - W/DECALS - LEFT - BLACK (INC. 9-20)

PANEL, SIDE - W/DECALS - LEFT - BLACK (INC. 9-20)

55 320 ₽
9

4718-553 ...PANEL, SIDE - W/O DECALS - LEFT - BLACK (INC. 10-12 AND 16-20)

...PANEL, SIDE - W/O DECALS - LEFT - BLACK (INC. 10-12 AND 16-20)

39 930 ₽
10

0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT

......FOAM, SIDE PANEL - UPPER REAR - LEFT

2 490 ₽
11

0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT

......FOAM, SIDE PANEL - LOWER REAR - LEFT

1 870 ₽
12

0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT

......FOAM, SIDE PANEL - LOWER FRONT - LEFT

860 ₽
13

2621-432 ...DECAL, SIDE PANEL - UPPER - RIGHT - BLACK

...DECAL, SIDE PANEL - UPPER - RIGHT - BLACK

6 440 ₽
13

2621-433 ...DECAL, SIDE PANEL - UPPER - LEFT - BLACK

...DECAL, SIDE PANEL - UPPER - LEFT - BLACK

6 440 ₽
14

2621-438 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK

...DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK

5 190 ₽
14

2621-439 ...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK

...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK

5 190 ₽
15

2621-436 ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT - BLACK

...DECAL, SIDE PANEL - LOWER FRONT - RIGHT - BLACK

2 910 ₽
15

2621-437 ...DECAL, SIDE PANEL - LOWER FRONT - LEFT - BLACK

...DECAL, SIDE PANEL - LOWER FRONT - LEFT - BLACK

2 910 ₽
16

1623-637 ...CLIP, U-NUT

...CLIP, U-NUT

380 ₽
17

0607-447 ...CABLE

...CABLE

810 ₽
18

0605-283 ...CLIP, HAIRPIN

...CLIP, HAIRPIN

190 ₽
19

8060-486 ...RIVET

...RIVET

60 ₽
20

8050-127 ...WASHER

...WASHER

210 ₽
21

1623-052 CLIP, U-NUT

CLIP, U-NUT

150 ₽
22

6606-925 SCREEN, INTAKE

SCREEN, INTAKE

5 190 ₽
23

2602-794 DUCT, INTAKE - INNER

DUCT, INTAKE - INNER

4 150 ₽
24

1623-030 CLIP, U-NUT

CLIP, U-NUT

150 ₽
25

2602-793 DUCT, INTAKE - OUTER - BLACK

DUCT, INTAKE - OUTER - BLACK

2 910 ₽
26

0619-206 FOIL, PROTECTIVE

FOIL, PROTECTIVE

34 730 ₽
27

5706-531 SCREEN, INTAKE

SCREEN, INTAKE

3 110 ₽
28

1702-369 DUCT, AIR - CLUTCH (INC. 29)

DUCT, AIR - CLUTCH (INC. 29)

5 820 ₽
29

6606-694 ...FOIL, PROTECTIVE

...FOIL, PROTECTIVE

560 ₽
30

4718-656 PLATE, SKID - W/DECALS - RIGHT - BLACK (INC. 31-38 AND 45)

PLATE, SKID - W/DECALS - RIGHT - BLACK (INC. 31-38 AND 45)

30 990 ₽
31

3718-422 ...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 32-38)

...PLATE, SKID - W/O DECALS - RIGHT - BLACK (INC. 32-38)

28 700 ₽
32

0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT

......FOAM, SKID PLATE - UPPER REAR - RIGHT

540 ₽
33

0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT

......FOAM, SKID PLATE - CENTER FRONT - RIGHT

6 440 ₽
34

0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT

......FOAM, SKID PLATE - UPPER FRONT - RIGHT

5 400 ₽
35

2612-850 ......FOIL, PROTECTIVE

......FOIL, PROTECTIVE

3 110 ₽
36

8061-708 ......RIVET

......RIVET

150 ₽
37

2612-754 ......DEFLECTOR, HEAT

......DEFLECTOR, HEAT

4 360 ₽
38

0123-802 ......WASHER

......WASHER

20 ₽
39

4718-657 PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 36, 38, AND 40-45)

PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 36, 38, AND 40-45)

16 430 ₽
40

3718-789 ...PLATE, SKID - W/O DECALS - LEFT - BLACK (INC. 36, 38, AND 41-44)

...PLATE, SKID - W/O DECALS - LEFT - BLACK (INC. 36, 38, AND 41-44)

16 430 ₽
41

0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT

......FOAM, SKID PLATE - UPPER FRONT - LEFT

2 490 ₽
42

0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT

......FOAM, SKID PLATE - CENTER FRONT - LEFT

2 490 ₽
43

0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT

......FOAM, SKID PLATE - UPPER REAR - LEFT

610 ₽
44

6606-613 ......PANEL, REINFORCEMENT

......PANEL, REINFORCEMENT

1 870 ₽
45

2621-440 ...DECAL, SKID PLATE - LOWER FRONT - RIGHT - BLACK

...DECAL, SKID PLATE - LOWER FRONT - RIGHT - BLACK

3 320 ₽
45

2621-441 ...DECAL, SKID PLATE - LOWER FRONT - LEFT - BLACK

...DECAL, SKID PLATE - LOWER FRONT - LEFT - BLACK

3 320 ₽
46

2623-005 CLIP, RETAINING

CLIP, RETAINING

400 ₽
47

6606-592 PIN, RETAINING

PIN, RETAINING

540 ₽
48

1623-129 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

230 ₽
49

2612-796 PLATE, EXHAUST OUTLET

PLATE, EXHAUST OUTLET

2 070 ₽
50

2612-795 SEAL, EXHAUST OUTLET

SEAL, EXHAUST OUTLET

2 700 ₽
51

8061-710 RIVET, BLIND - LARGE FLANGE - SS68 - BLACK

RIVET, BLIND - LARGE FLANGE - SS68 - BLACK

170 ₽
52

6606-295 SHIELD, HEAT - ECM

SHIELD, HEAT - ECM

3 740 ₽
53

8408-620 SCREW, CAP

SCREW, CAP

110 ₽
54

0423-031 CLIP, U-NUT

CLIP, U-NUT

150 ₽
55

0623-784 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

210 ₽
56

6606-342 FASCIA, FRONT - RIGHT - BLACK

FASCIA, FRONT - RIGHT - BLACK

2 910 ₽
56

3718-303 FASCIA, FRONT - LEFT - BLACK (INC. 57)

FASCIA, FRONT - LEFT - BLACK (INC. 57)

2 910 ₽
57

6606-405 ...FOIL, PROTECTIVE

...FOIL, PROTECTIVE

4 150 ₽
58

2623-001 NUT, PUSH

NUT, PUSH

60 ₽
59

1623-999 SCREW, THUMB

SCREW, THUMB

750 ₽
