DRIVE CLUTCH для Arctic Cat BEARCAT 7000 XT BLUE - 2017 года выпуска
-
№АртикулНазвание
-
10746-880 CLUTCH, DRIVE - UNCALIBRATED (INC. 2, 4-8, 10-13)CLUTCH, DRIVE - UNCALIBRATED (INC. 2, 4-8, 10-13)
-
20646-950 ...SCREW, SHOULDER...SCREW, SHOULDER
-
30646-469 SPRING, DRIVE CLUTCHSPRING, DRIVE CLUTCH
-
40646-466 NUT, JAMNUT, JAM
-
50646-953 SPIDERSPIDER
-
60646-951 PLUG, TORQUE BUTTONPLUG, TORQUE BUTTON
-
70646-465 BUTTON, TORQUE - PRIMARYBUTTON, TORQUE - PRIMARY
-
80646-964 SHIM - 1.27X210X0.70SHIM - 1.27X210X0.70
-
80646-965 SHIM - 1.35X1.575X0.030SHIM - 1.35X1.575X0.030
-
97639-127 KIT, CAM ARM (INC. 10-13)KIT, CAM ARM (INC. 10-13)
-
100823-396 ...PIN, CAM ARM...PIN, CAM ARM
-
112623-091 ...WASHER...WASHER
-
120823-399 ...NUT, LOCK...NUT, LOCK
-
130646-880 ...WASHER, THRUST...WASHER, THRUST
-
140646-864 ARM, CAMARM, CAM
-
150623-210 WASHER, HIGH COLLARWASHER, HIGH COLLAR
-
160623-804 BOLT, CLUTCHBOLT, CLUTCH
