SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat XF 6000 CROSSTREK ES 137 INTERNATIONAL GREEN - 2017 года выпуска
-
№АртикулНазвание
-
15718-060 PANEL, SIDE - W/DECALS - RIGHT - GREEN (INC. 2-7, 13-15, 17-20, AND 59)PANEL, SIDE - W/DECALS - RIGHT - GREEN (INC. 2-7, 13-15, 17-20, AND 59)
-
23718-858 ...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 17-20)...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 17-20)
-
30617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
-
46606-414 ......FOIL, PROTECTIVE - MIDDLE PANEL - RIGHT......FOIL, PROTECTIVE - MIDDLE PANEL - RIGHT
-
50617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT......FOAM, SIDE PANEL - UPPER REAR - RIGHT
-
60617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
-
70617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT......FOAM, SIDE PANEL - LOWER REAR - RIGHT
-
85718-061 PANEL, SIDE - W/DECALS - LEFT - GREEN (INC. 9-20)PANEL, SIDE - W/DECALS - LEFT - GREEN (INC. 9-20)
-
94718-577 ...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-12 AND 16-20)...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-12 AND 16-20)
-
100617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT......FOAM, SIDE PANEL - UPPER REAR - LEFT
-
110617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT......FOAM, SIDE PANEL - LOWER REAR - LEFT
-
120617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT......FOAM, SIDE PANEL - LOWER FRONT - LEFT
-
133621-140 ...DECAL, SIDE PANEL - UPPER - RIGHT...DECAL, SIDE PANEL - UPPER - RIGHT
-
133621-141 ...DECAL, SIDE PANEL - UPPER - LEFT...DECAL, SIDE PANEL - UPPER - LEFT
-
143621-144 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT...DECAL, SIDE PANEL - LOWER REAR - RIGHT
-
143621-145 ...DECAL, SIDE PANEL - LOWER REAR - LEFT...DECAL, SIDE PANEL - LOWER REAR - LEFT
-
153621-146 ...DECAL, SIDE PANEL - "6000" - RIGHT - BLACK...DECAL, SIDE PANEL - "6000" - RIGHT - BLACK
-
153621-147 ...DECAL, SIDE PANEL - "6000" - LEFT -BLACK...DECAL, SIDE PANEL - "6000" - LEFT -BLACK
-
161623-637 ...CLIP, U-NUT...CLIP, U-NUT
-
170607-447 ...CABLE...CABLE
-
180605-283 ...CLIP, HAIRPIN...CLIP, HAIRPIN
-
198060-486 ...RIVET...RIVET
-
208050-127 ...WASHER...WASHER
-
211623-129 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
221623-052 CLIP, U-NUTCLIP, U-NUT
-
236606-925 SCREEN, INTAKESCREEN, INTAKE
-
242602-794 DUCT, INTAKE - INNERDUCT, INTAKE - INNER
-
251623-030 CLIP, U-NUTCLIP, U-NUT
-
262602-801 DUCT, INTAKE - OUTER - GREENDUCT, INTAKE - OUTER - GREEN
-
270619-206 FOIL, PROTECTIVEFOIL, PROTECTIVE
-
286606-925 SCREEN, INTAKESCREEN, INTAKE
-
291702-369 DUCT, BELT COOLING (INC. 30)DUCT, BELT COOLING (INC. 30)
-
306606-694 ...FOIL, PROTECTIVE...FOIL, PROTECTIVE
-
314718-158 PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 32-38)PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 32-38)
-
320617-640 ...FOAM, SKID PLATE - UPPER REAR - RIGHT...FOAM, SKID PLATE - UPPER REAR - RIGHT
-
330617-638 ...FOAM, SKID PLATE - CENTER FRONT - RIGHT...FOAM, SKID PLATE - CENTER FRONT - RIGHT
-
340617-636 ...FOAM, SKID PLATE - UPPER FRONT - RIGHT...FOAM, SKID PLATE - UPPER FRONT - RIGHT
-
352612-970 ...FOIL, PROTECTIVE - RIGHT...FOIL, PROTECTIVE - RIGHT
-
368061-708 ...RIVET...RIVET
-
372612-754 ...DEFLECTOR, HEAT...DEFLECTOR, HEAT
-
380123-802 ...WASHER...WASHER
-
393718-789 PLATE, SKID - LEFT W/FOAM - BLACK (INC. 36, 38, AND 40-43)PLATE, SKID - LEFT W/FOAM - BLACK (INC. 36, 38, AND 40-43)
-
400617-637 ...FOAM, SKID PLATE - UPPER FRONT - LEFT...FOAM, SKID PLATE - UPPER FRONT - LEFT
-
410617-639 ...FOAM, SKID PLATE - CENTER FRONT - LEFT...FOAM, SKID PLATE - CENTER FRONT - LEFT
-
420617-641 ...FOAM, SKID PLATE - UPPER REAR - LEFT...FOAM, SKID PLATE - UPPER REAR - LEFT
-
436606-613 ...PANEL, REINFORCEMENT...PANEL, REINFORCEMENT
-
442623-005 CLIP, RETAININGCLIP, RETAINING
-
456606-592 PIN, RETAININGPIN, RETAINING
-
462612-972 PLATE, EXHAUST OUTLETPLATE, EXHAUST OUTLET
-
472612-971 SEAL, EXHAUST OUTLETSEAL, EXHAUST OUTLET
-
481712-963 DEFLECTOR, EXHAUST OUTLET - BLACKDEFLECTOR, EXHAUST OUTLET - BLACK
-
498061-710 RIVETRIVET
-
506606-940 SHIELD, HEAT - ECMSHIELD, HEAT - ECM
-
518408-620 SCREW, CAPSCREW, CAP
-
520730-266 ECMECM
-
530423-031 NUT, SPEEDNUT, SPEED
-
540623-784 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
556606-342 FASCIA, FRONT - RIGHT - BLACKFASCIA, FRONT - RIGHT - BLACK
-
553718-303 FASCIA, FRONT - LEFT - BLACK (INC. 56)FASCIA, FRONT - LEFT - BLACK (INC. 56)
-
566606-405 ...FOIL, PROTECTIVE - FILLER PANEL - LEFT...FOIL, PROTECTIVE - FILLER PANEL - LEFT
-
572623-001 NUT, PUSH (OPT.)NUT, PUSH (OPT.)
-
581623-999 SCREW, THUMB (OPT.)SCREW, THUMB (OPT.)
-
593621-142 DECAL, SIDE PANEL - MID - RIGHTDECAL, SIDE PANEL - MID - RIGHT
-
593621-155 DECAL, SIDE PANEL - VENT - LEFTDECAL, SIDE PANEL - VENT - LEFT
