CYLINDER HEAD ASSEMBLY для Arctic Cat XF 9000 HIGH COUNTRY LTD 153 2.2 BLACK INTERNATIONAL - 2017 года выпуска
-
№АртикулНазвание
-
13020-168 COIL, IGNITIONCOIL, IGNITION
-
20217-705 PLUG, SPARKPLUG, SPARK
-
33020-169 SCREW, SHOULDERSCREW, SHOULDER
-
43020-170 GROMMETGROMMET
-
53020-171 PLUGPLUG
-
63020-172 O-RINGO-RING
-
73020-568 COVER, CYLINDER HEADCOVER, CYLINDER HEAD
-
83020-174 GUIDE, CHAINGUIDE, CHAIN
-
93020-420 GASKET, CYLINDER COVERGASKET, CYLINDER COVER
-
103020-563 HEAD, CYLINDER - ASSEMBLY (INC. 11-15)HEAD, CYLINDER - ASSEMBLY (INC. 11-15)
-
113020-177 ...GUIDE, VALVE - INTAKE...GUIDE, VALVE - INTAKE
-
123020-178 ...GUIDE, VALVE - EXHAUST...GUIDE, VALVE - EXHAUST
-
133020-142 ...PLUG...PLUG
-
143020-179 ...SCREW, CAP...SCREW, CAP
-
153020-180 ...PIN, DOWEL...PIN, DOWEL
-
163020-566 GASKETGASKET
-
173020-183 SCREW, CAPSCREW, CAP
-
183020-567 SCREW, CAPSCREW, CAP
-
193020-569 GASKET, CYLINDER HEADGASKET, CYLINDER HEAD
-
203020-565 UNIT, THERMOUNIT, THERMO
-
213020-564 BOLT, STUD (M9 STUD)BOLT, STUD (M9 STUD)
-
220410-143 HOSE - 25 FTHOSE - 25 FT
-
231623-966 CLAMP, HOSECLAMP, HOSE
