SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 6000 RR ES 129 GREEN - 2017 года выпуска

№

Артикул

Название
1

5718-170 PANEL, SIDE - W/DECALS - RIGHT - GREEN (INC. 2-7, 13-15, AND 17-20)

PANEL, SIDE - W/DECALS - RIGHT - GREEN (INC. 2-7, 13-15, AND 17-20)

50 750 ₽
2

3718-858 ...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 16-20)

...PANEL, SIDE - W/O DECALS - RIGHT - GREEN (INC. 3-7 AND 16-20)

39 930 ₽
3

0617-626 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

......FOAM, SIDE PANEL - UPPER FRONT - RIGHT

650 ₽
4

6606-414 ......FOIL, PROTECTIVE - CENTER PANEL - RIGHT

......FOIL, PROTECTIVE - CENTER PANEL - RIGHT

290 ₽
5

0617-628 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT

......FOAM, SIDE PANEL - UPPER REAR - RIGHT

5 400 ₽
6

0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

......FOAM, SIDE PANEL - LOWER FRONT - RIGHT

3 320 ₽
7

0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT

......FOAM, SIDE PANEL - LOWER REAR - RIGHT

5 820 ₽
8

5718-171 PANEL, SIDE - W/DECALS - LEFT - GREEN (INC. 9-20)

PANEL, SIDE - W/DECALS - LEFT - GREEN (INC. 9-20)

50 750 ₽
9

4718-577 ...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-12 AND 16-20)

...PANEL, SIDE - W/O DECALS - LEFT - GREEN (INC. 10-12 AND 16-20)

38 680 ₽
10

0617-629 ......FOAM, SIDE PANEL - UPPER REAR - LEFT

......FOAM, SIDE PANEL - UPPER REAR - LEFT

2 490 ₽
11

0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT

......FOAM, SIDE PANEL - LOWER REAR - LEFT

1 870 ₽
12

0617-681 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT

......FOAM, SIDE PANEL - LOWER FRONT - LEFT

860 ₽
13

3621-134 ...DECAL, SIDE PANEL - UPPER - RIGHT

...DECAL, SIDE PANEL - UPPER - RIGHT

7 900 ₽
13

3621-135 ...DECAL, SIDE PANEL - UPPER - LEFT

...DECAL, SIDE PANEL - UPPER - LEFT

7 900 ₽
14

3621-382 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK

...DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK

6 860 ₽
14

3621-383 ...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK

...DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK

6 860 ₽
15

3621-378 ...DECAL, SIDE PANEL - FRONT - RIGHT - "6000R" - BLACK

...DECAL, SIDE PANEL - FRONT - RIGHT - "6000R" - BLACK

2 700 ₽
15

3621-379 ...DECAL, SIDE PANEL - FRONT - LEFT - "6000R" - BLACK

...DECAL, SIDE PANEL - FRONT - LEFT - "6000R" - BLACK

2 700 ₽
16

1623-637 ...CLIP, U-NUT

...CLIP, U-NUT

380 ₽
17

0607-447 ...CABLE

...CABLE

810 ₽
18

0605-283 ...CLIP, HAIRPIN

...CLIP, HAIRPIN

190 ₽
19

8060-486 ...RIVET

...RIVET

60 ₽
20

8050-127 ...WASHER

...WASHER

210 ₽
21

1623-129 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

230 ₽
22

1623-052 CLIP, U-NUT

CLIP, U-NUT

150 ₽
23

6606-925 SCREEN, INTAKE

SCREEN, INTAKE

5 190 ₽
24

2602-794 DUCT, INTAKE - INNER

DUCT, INTAKE - INNER

4 150 ₽
25

1623-030 CLIP, U-NUT

CLIP, U-NUT

150 ₽
26

2602-801 DUCT, INTAKE - OUTER - GREEN

DUCT, INTAKE - OUTER - GREEN

2 910 ₽
27

0619-206 FOIL, PROTECTIVE

FOIL, PROTECTIVE

34 730 ₽
28

6606-925 SCREEN, INTAKE

SCREEN, INTAKE

5 190 ₽
29

1702-369 DUCT, BELT COOLING (INC. 30)

DUCT, BELT COOLING (INC. 30)

5 820 ₽
30

6606-694 ...FOIL, PROTECTIVE

...FOIL, PROTECTIVE

560 ₽
31

5718-148 PLATE, SKID - RIGHT - W/DECAL (INC. 32-39, AND 40-41)

PLATE, SKID - RIGHT - W/DECAL (INC. 32-39, AND 40-41)

29 950 ₽
32

4718-158 ...PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 33-39)

...PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 33-39)

28 700 ₽
33

0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT

......FOAM, SKID PLATE - UPPER REAR - RIGHT

540 ₽
34

0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT

......FOAM, SKID PLATE - CENTER FRONT - RIGHT

6 440 ₽
35

0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT

......FOAM, SKID PLATE - UPPER FRONT - RIGHT

5 400 ₽
36

2612-970 ......FOIL, PROTECTIVE - RIGHT

......FOIL, PROTECTIVE - RIGHT

1 450 ₽
37

8061-708 ......RIVET

......RIVET

150 ₽
38

2612-754 ......DEFLECTOR, HEAT

......DEFLECTOR, HEAT

4 360 ₽
39

0123-802 ......WASHER

......WASHER

20 ₽
40

3621-124 ...DECAL, SKID PLATE - REAR - RIGHT

...DECAL, SKID PLATE - REAR - RIGHT

2 070 ₽
40

3621-125 ...DECAL, SKID PLATE - FRONT - LEFT

...DECAL, SKID PLATE - FRONT - LEFT

2 070 ₽
41

3621-126 ...DECAL, SKID PLATE - FRONT - RIGHT

...DECAL, SKID PLATE - FRONT - RIGHT

3 110 ₽
41

3621-127 ...DECAL, SKID PLATE - REAR - LEFT

...DECAL, SKID PLATE - REAR - LEFT

3 110 ₽
42

4718-993 PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 37, 39-41 AND 43-47)

PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 37, 39-41 AND 43-47)

18 920 ₽
43

3718-789 ...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 37, 39, AND 44-47)

...PLATE, SKID - LEFT W/FOAM - BLACK (INC. 37, 39, AND 44-47)

16 430 ₽
44

0617-637 ......FOAM, SKID PLATE - UPPER FRONT - LEFT

......FOAM, SKID PLATE - UPPER FRONT - LEFT

2 490 ₽
45

0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT

......FOAM, SKID PLATE - CENTER FRONT - LEFT

2 490 ₽
46

0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT

......FOAM, SKID PLATE - UPPER REAR - LEFT

610 ₽
47

6606-613 ......PANEL, REINFORCEMENT

......PANEL, REINFORCEMENT

1 870 ₽
48

2623-005 CLIP, RETAINING

CLIP, RETAINING

400 ₽
49

6606-592 PIN, RETAINING

PIN, RETAINING

540 ₽
50

2612-972 PLATE, EXHAUST OUTLET

PLATE, EXHAUST OUTLET

2 280 ₽
51

2612-971 SEAL, EXHAUST OUTLET

SEAL, EXHAUST OUTLET

5 610 ₽
52

1712-963 DEFLECTOR, EXHAUST OUTLET - BLACK

DEFLECTOR, EXHAUST OUTLET - BLACK

4 780 ₽
53

8061-710 RIVET

RIVET

170 ₽
54

6606-940 SHIELD, HEAT - ECM

SHIELD, HEAT - ECM

3 530 ₽
55

8408-620 SCREW, CAP

SCREW, CAP

110 ₽
56

0730-266 ECM

ECM

310 ₽
57

0423-031 NUT, SPEED

NUT, SPEED

150 ₽
58

0623-784 SCREW, SELF-TAPPING

SCREW, SELF-TAPPING

210 ₽
59

6606-342 FASCIA, FRONT - RIGHT - BLACK

FASCIA, FRONT - RIGHT - BLACK

2 910 ₽
59

3718-303 FASCIA, FRONT - LEFT - BLACK (INC. 60)

FASCIA, FRONT - LEFT - BLACK (INC. 60)

2 910 ₽
60

6606-405 ...FOIL, PROTECTIVE - FILLER PANEL - LEFT

...FOIL, PROTECTIVE - FILLER PANEL - LEFT

4 150 ₽
61

2623-001 NUT, PUSH

NUT, PUSH

60 ₽
62

1623-999 SCREW, THUMB

SCREW, THUMB

750 ₽
63

2621-903 DECAL, SIDE PANEL - MID VENT - LEFT

DECAL, SIDE PANEL - MID VENT - LEFT

520 ₽
