STEERING POST ASSEMBLY для Arctic Cat M 8000 MOUNTAIN CAT 153 BLACK EARLY BUILD - 2018 года выпуска
-
№АртикулНазвание
-
18477-830 SCREW, MACHINESCREW, MACHINE
-
21705-461 CAP, RISER BLOCK - BLACKCAP, RISER BLOCK - BLACK
-
31705-415 BLOCK, RISER - BLACKBLOCK, RISER - BLACK
-
48408-830 SCREW, CAPSCREW, CAP
-
51705-558 POST, STEERING - UPPERPOST, STEERING - UPPER
-
61605-054 BEARING - RIGHTBEARING - RIGHT
-
61605-055 BEARING - LEFTBEARING - LEFT
-
71605-056 RING, RETAININGRING, RETAINING
-
80623-175 PIN, COTTERPIN, COTTER
-
91605-067 WASHER, THRUSTWASHER, THRUST
-
108427-802 NUTNUT
-
111705-397 BRACKET, STEERING SUPPORT (INC. 12)BRACKET, STEERING SUPPORT (INC. 12)
-
121605-057 ...BEARING...BEARING
-
138427-602 NUT, LOCKNUT, LOCK
-
148476-625 SCREW, CAPSCREW, CAP
-
158468-625 SCREW, MACHINESCREW, MACHINE
-
162623-202 NUT, LOCK W/WASHERNUT, LOCK W/WASHER
-
178422-602 NUTNUT
-
181705-524 POST, STEERING - LOWERPOST, STEERING - LOWER
-
192623-026 SCREW, MACHINESCREW, MACHINE
-
201605-032 BALL JOINT, TIE ROD - RIGHT-HAND THREADBALL JOINT, TIE ROD - RIGHT-HAND THREAD
-
218420-002 NUT - RIGHT-HAND THREADNUT - RIGHT-HAND THREAD
-
221605-053 TUBE, TIE RODTUBE, TIE ROD
-
230423-013 NUT - LEFT-HAND THREADNUT - LEFT-HAND THREAD
-
241605-051 BALL JOINT, STEERING - LEFT-HAND THREADBALL JOINT, STEERING - LEFT-HAND THREAD
-
252623-079 SCREW, MACHINESCREW, MACHINE
-
261605-128 BLOCK, MOUNTING - STEERING POST - LOWERBLOCK, MOUNTING - STEERING POST - LOWER
-
271605-127 BLOCK, MOUNTING - STEERING POST - UPPERBLOCK, MOUNTING - STEERING POST - UPPER
-
280605-998 PLATE, RETAININGPLATE, RETAINING
-
290902-034 COIL, IGNITION - ASSEMBLY (INC. 30)COIL, IGNITION - ASSEMBLY (INC. 30)
-
303006-367 ...CAP, SPARK PLUG...CAP, SPARK PLUG
-
310608-706 PLATE, RETAININGPLATE, RETAINING
Все узлы модели:
- A-ARM ASSEMBLY
- BELT GUARD ASSEMBLY
- BUMPERS AND STORAGE
- CHAIN CASE ASSEMBLY
- CONSOLE ASSEMBLY
- COOLING ASSEMBLY
- CRANKCASE ASSEMBLY
- CYLINDER AND HEAD ASSEMBLY
- DECALS
- DRIVE CLUTCH
- DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES
- DRIVEN CLUTCH
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- FRONT FRAME ASSEMBLY
- FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY
- FUEL PUMP ASSEMBLY
- GAS TANK ASSEMBLY
- HANDLEBAR AND CONTROLS
- HEADLIGHT AND WIRING ASSEMBLIES
- HOOD AND AIR INTAKE ASSEMBLY
- HYDRAULIC BRAKE CONTROL ASSEMBLY
- IDLER WHEEL ASSEMBLY
- MAGNETO
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT
- REAR SUSPENSION FRONT ARM ASSEMBLY
- REAR SUSPENSION FRONT ARM SHOCK ABSORBER
- REAR SUSPENSION REAR ARM ASSEMBLY
- REAR SUSPENSION REAR ARM SHOCK ABSORBER
- RECOIL STARTER
- REED VALVE ASSEMBLY
- SEAT ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SKID PLATE AND SIDE PANEL ASSEMBLY
- SLIDE RAIL AND TRACK ASSEMBLY
- • STEERING POST ASSEMBLY
- STEERING SUPPORT ASSEMBLY
- THROTTLE BODY ASSEMBLY
- TIE ROD ASSEMBLY
- TUNNEL AND SNOWFLAP ASSEMBLY
- WATER PUMP AND THERMOSTAT
- WINDSHIELD AND INSTRUME
