FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY для Arctic Cat M 8000 MOUNTAIN CAT ES 153 BLACK - 2018 года выпуска
-
№АртикулНазвание
-
13703-762 SHOCK, SKI - RIGHT (INC. 2-12)SHOCK, SKI - RIGHT (INC. 2-12)
-
13703-763 SHOCK, SKI - LEFT (INC. 2-12)SHOCK, SKI - LEFT (INC. 2-12)
-
23603-366 ...CAP, AIR VALVE - W/O-RING...CAP, AIR VALVE - W/O-RING
-
32603-511 ...VALVE, AIR...VALVE, AIR
-
43603-623 ...DAMPING, ADJUST KNOB...DAMPING, ADJUST KNOB
-
53603-377 ...SCREW, MACHINE...SCREW, MACHINE
-
63603-523 ...DECAL, BASE VALUE...DECAL, BASE VALUE
-
73603-633 ...DECAL...DECAL
-
83603-632 ...DECAL...DECAL
-
93603-631 ...DECAL, "PERFORMANCE SERIES"...DECAL, "PERFORMANCE SERIES"
-
103603-638 ...DECAL, FLOAT 3...DECAL, FLOAT 3
-
113603-359 ...DECAL, PSI...DECAL, PSI
-
124604-333 ...KIT, SEAL/CAP REBUILD...KIT, SEAL/CAP REBUILD
-
138413-850 SCREW, CAPSCREW, CAP
-
143603-260 BUSHINGBUSHING
-
153603-261 SLEEVESLEEVE
-
168437-804 NUT, LOCKNUT, LOCK
-
170641-257 PUMP, SHOCKPUMP, SHOCK
-
184639-012 FLUID, FLOAT SHOCK - 8 OZFLUID, FLOAT SHOCK - 8 OZ
-
195639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
