MAGNETO для Arctic Cat ZR 6000 CROSSTREK ES 137 GREEN - 2018 года выпуска
-
№АртикулНазвание
-
10923-054 SCREW, CAPSCREW, CAP
-
20902-038 BRACKET, RETAININGBRACKET, RETAINING
-
30902-005 SENSOR, IGNITION TIMINGSENSOR, IGNITION TIMING
-
40902-022 GROMMETGROMMET
-
50923-002 SCREW, CAPSCREW, CAP
-
60902-020 BRACKET, RETAININGBRACKET, RETAINING
-
70902-006 SENSOR, IGNITION TIMINGSENSOR, IGNITION TIMING
-
80902-021 GROMMETGROMMET
-
90923-033 SCREW, CAPSCREW, CAP
-
100923-032 WASHERWASHER
-
110902-026 ROTOR/FLYWHEELROTOR/FLYWHEEL
-
120923-027 SCREW, CAPSCREW, CAP
-
130902-017 STATORSTATOR
-
141619-131 CONDUIT, FLEXIBLE ((3/4 IN. ID) - 12 IN.)CONDUIT, FLEXIBLE ((3/4 IN. ID) - 12 IN.)
-
150123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
160923-024 SCREW, CAPSCREW, CAP
-
170902-014 PLATE, BASE - STATORPLATE, BASE - STATOR
