09- Body _34S1409 для BRP WAKE PRO 215 - 2014
-
№АртикулНазвание
-
2205063060 Socket Head Screw M6 X 30Socket Head Screw M6 X 30
-
7211000023 Hex. Screw 10-14 X 7/8''Hex. Screw 10-14 X 7/8''
-
10219903228 Warning WAKEWarning WAKE
-
11219903240 WAKE-PRO DecalWAKE-PRO Decal
-
12230060060 Hex. Screw M6 X 100Hex. Screw M6 X 100
-
14232561200 Elastic Stop Nut M6, BrassElastic Stop Nut M6, Brass
-
15232581200 Hex. Elastic Nut M8, BrassHex. Elastic Nut M8, Brass
-
16233161600 Hex. Flanged Nut M6Hex. Flanged Nut M6
-
19234042600 Flat Washer 4 mm, StainlessFlat Washer 4 mm, Stainless
-
23241141360 Hex. Flanged Screw K40 X 13Hex. Flanged Screw K40 X 13
-
25241142560 Hex. Flanged Screw K40 X 25Hex. Flanged Screw K40 X 25
-
28250000287 Flanged Torx Screw K40 X 16Flanged Torx Screw K40 X 16
-
30250000452 Torx Screw M8 X 40, StainlessTorx Screw M8 X 40, Stainless
-
31250000466 Torx Screw Plastite M6Torx Screw Plastite M6
-
32250200011 Flat Washer 8 mm, StainlessFlat Washer 8 mm, Stainless
-
34269002162 Mounting Case AbsorberMounting Case Absorber
-
35291004622 Black Rear HandleBlack Rear Handle
-
36269500252 M6 Nut Housing Ass'yM6 Nut Housing Ass'y
-
37269501166 Nut Housing Ass'yNut Housing Ass'y
-
38269501299 StrapStrap
-
39269501651 Ball SpringBall Spring
-
43291001519 Bumper Plug, BlackBumper Plug, Black
-
44291002553 Support Sub-assemblySupport Sub-assembly
-
45291002592 Rear BumberRear Bumber
-
46291002625 Rear Plat-Form CarpetRear Plat-Form Carpet
-
48291002642 Aluminum PostAluminum Post
-
49291002920 LH Upper CapLH Upper Cap
-
49291002922 RH Upper CapRH Upper Cap
-
50291002711 LH Lateral ArmLH Lateral Arm
-
51291002712 RH Lateral ArmRH Lateral Arm
-
60291002756 Front Rewinder CapFront Rewinder Cap
-
62291002812 Molded HandleMolded Handle
-
63291002818 Deck NoseDeck Nose
-
64291003101 Board Support KitBoard Support Kit
-
65291002864 Lower AnchorageLower Anchorage
-
66291002930 LH Front CarpetLH Front Carpet
-
67291002931 RH Front CarpetRH Front Carpet
-
68291002932 LH Center CarpetLH Center Carpet
-
69291002933 RH Center CarpetRH Center Carpet
-
70291002934 LH Rear CarpetLH Rear Carpet
-
71291002935 RH Rear CarpetRH Rear Carpet
-
73291003508 RH Front Cover Ass'yRH Front Cover Ass'y
-
73291003511 LH Front Cover Ass'yLH Front Cover Ass'y
-
76291002979 Elastic Rope Ass'yElastic Rope Ass'y
-
77291002980 LatchLatch
-
80291003101 Board Support KitBoard Support Kit
-
81291003582 Upper AnchorageUpper Anchorage
-
82291003680 Front ModuleFront Module
-
84291003686 LH Access CoverLH Access Cover
-
84291003687 RH Access CoverRH Access Cover
-
85291003688 Rubber BumperRubber Bumper
-
86291004275 Front BumperFront Bumper
-
87291003872 Lateral BumperLateral Bumper
-
92291003987 RH Seat Pad, BlackRH Seat Pad, Black
-
92291003988 LH Seat Pad, BlackLH Seat Pad, Black
-
95293050001 Flat WasherFlat Washer
-
98219903137 Warning LabelWarning Label
-
100293150167 Type ''U'' Metallic Drive ScrewType ''U'' Metallic Drive Screw
-
101293200133 Neoprene SealNeoprene Seal
-
103293250151 SealSeal
-
104293250183 StrapStrap
-
108293300121 O-RingO-Ring
-
109293350062 Ball 1/4''Ball 1/4''
-
113293830005 Rubber BumperRubber Bumper
-
114293830037 Rubber WasherRubber Washer
-
115293830119 Rubber BufferRubber Buffer
