09- Luggage Rack _36M1521 для BRP Ski-Doo GSX LE 1200 XR137 - 2015
-
№АртикулНазвание
-
1233251494 Elastic Flanged Nut M5Elastic Flanged Nut M5
-
2250000297 Truss Head Torx Screw K50 X 20Truss Head Torx Screw K50 X 20
-
3250000446 Torx Screw M6 X 20, Scotch GripTorx Screw M6 X 20, Scotch Grip
-
4293150067 RivetRivet
-
5293150103 Black Pop Rivet 3/16''Black Pop Rivet 3/16''
-
6511000568 Deep Black Trunk CoverDeep Black Trunk Cover
-
7511000528 BracketBracket
-
8511000590 Radiator Cover, 137''Radiator Cover, 137''
-
9511001048 Radiator Cover, 128''Radiator Cover, 128''
-
10511000757 TrunkTrunk
-
11511000822 InsertInsert
-
12511000779 Cargo BaseCargo Base
-
13860200620 Bag Ass'yBag Ass'y
