07- Front Drive - 1000R для BRP 005 - Maverick Sport 1000R - XRC - North America - 2019
-
№АртикулНазвание
-
10705402005 Drive Shaft Ass'y. Includes 10 to 10bDrive Shaft Ass'y. Includes 10 to 10b
-
10a715900400 Fixed YokeFixed Yoke
-
10b715900401 YokeYoke
-
10c715900402 J-Joint Cross KitJ-Joint Cross Kit
-
15705402006 Drive Shaft Ass'yDrive Shaft Ass'y
-
16705401938 BearingBearing
-
17293370098 Snap RingSnap Ring
-
18207502046 Hex. Flanged Screw M10 X 20Hex. Flanged Screw M10 X 20
-
30705402371 Front Differential Ass.Front Differential Ass.
-
40705402282 Front Half Shaft. Includes 40 to 40fFront Half Shaft. Includes 40 to 40f
-
40a715900619 CV JointCV Joint
-
40b715900568 Plunging JointPlunging Joint
-
40c715900569 CirclipCirclip
-
40d705401354 Boot Kit, Wheel Side. Includes 40d to 40d2Boot Kit, Wheel Side. Includes 40d to 40d2
-
40d1715900260 Oetiker Clamp, LargeOetiker Clamp, Large
-
40d2715900261 Oetiker Clamp, SmallOetiker Clamp, Small
-
40e705401355 Boot Kit, Differential Side. Includes 40e to 40e2Boot Kit, Differential Side. Includes 40e to 40e2
-
40e1715900261 Oetiker Clamp, SmallOetiker Clamp, Small
-
40e2715900262 Oetiker Clamp, LargeOetiker Clamp, Large
-
40f715900580 O-ringO-ring
-
320250001050 Hex. Flanged Screw M8 X 42Hex. Flanged Screw M8 X 42
-
325233281416 Hex. Elastic Flanged Nut M8Hex. Elastic Flanged Nut M8
