GEAR CHANGE DRUM/SHIFT FORK(S) для Kawasaki KFX 90 (KSF90A7F) - 2007 года выпуска
-
№АртикулНазвание
-
1106111061-Y016 GASKET, GEAR CASEGASKET, GEAR CASE
-
1310713107-Y004 SHAFT, FINALSHAFT, FINAL
-
1323413234-Y001 SHAFT-COMPSHAFT-COMP
-
1327113271-Y007 PLATEPLATE
-
1402614026-Y001 COVER-CHAINCOVER-CHAIN
-
1405514055-Y001 CASE-GEARCASE-GEAR
-
1608516085-Y004 GEAR, FINALGEAR, FINAL
-
3913439134-Y001 SPROCKET-DRIVESPROCKET-DRIVE
-
3915939159-Y001 SHAFT-DRIVESHAFT-DRIVE
-
9203392033-Y011 RING-SNAPRING-SNAP
-
9204392043-Y001 PIN, BRAKEPIN, BRAKE
-
92043A92043-Y014 PIN, DOWEL, 10X20PIN, DOWEL, 10X20
-
9204592045-Y002 BEARING-BALL, 6201BEARING-BALL, 6201
-
92045A92045-Y005 BEARING-BALL, 6004 UUBEARING-BALL, 6004 UU
-
9204992049-Y008 SEAL-OIL, 27X42X7SEAL-OIL, 27X42X7
-
9205592055-Y002 RING-O, 7.5X1.5RING-O, 7.5X1.5
-
9205792057-Y004 CHAIN, DRIVECHAIN, DRIVE
-
9215392153-Y014 BOLT, 6X10BOLT, 6X10
-
92153A92153-Y045 BOLT, FLANGE, 6X10BOLT, FLANGE, 6X10
-
9220092200-Y004 WASHER, 12MMWASHER, 12MM
-
92200A92200-Y007 WASHER, 15MMWASHER, 15MM
-
9221092210-Y014 NUT, 8MMNUT, 8MM
