CYLINDER HEAD для Kawasaki KFX 90 (KSF90ADF) - 2013 года выпуска
-
№АртикулНазвание
-
1100411004-Y002 GASKET-HEADGASKET-HEAD
-
1100811008-Y004 HEAD-COMP-CYLINDERHEAD-COMP-CYLINDER
-
1106111061-Y010 GASKET, CYLINDER HEAD COVERGASKET, CYLINDER HEAD COVER
-
11061A11061-Y018 GASKETGASKET
-
11061B11061-Y020 GASKETGASKET
-
1200412004-Y002 VALVE-INTAKEVALVE-INTAKE
-
1200512005-Y002 VALVE-EXHAUSTVALVE-EXHAUST
-
1200912009-Y001 RETAINER-VALVE SPRINGRETAINER-VALVE SPRING
-
1201112011-Y001 COLLETCOLLET
-
1201612016-Y001 ARM-ROCKERARM-ROCKER
-
1202012020-Y001 SHAFT-ROCKER, INSHAFT-ROCKER, IN
-
12020A12020-Y003 SHAFT-ROCKER, EXSHAFT-ROCKER, EX
-
1202112021-Y002 VALVE-ASSY-REEDVALVE-ASSY-REED
-
1328013280-Y002 HOLDER, CAMSHAFTHOLDER, CAMSHAFT
-
1409114091-Y015 COVER, REED VALVECOVER, REED VALVE
-
14091A14091-Y016 COVER, CYLINDER HEADCOVER, CYLINDER HEAD
-
1600716007-Y001 SEAT-SPRINGSEAT-SPRING
-
1606016060-Y004 PIPE-INTAKEPIPE-INTAKE
-
1607316073-Y002 INSULATORINSULATOR
-
3106431064-Y003 PIPE-COMPPIPE-COMP
-
4907849078-Y002 SPRING-ENGINE VALVE, OUTERSPRING-ENGINE VALVE, OUTER
-
49078A49078-Y003 SPRING-ENGINE VALVE, INNERSPRING-ENGINE VALVE, INNER
-
4911849118-Y002 CAMSHAFT-COMPCAMSHAFT-COMP
-
9200492004-Y006 STUD, 8X32STUD, 8X32
-
92004A92004-Y007 STUD, 6X50STUD, 6X50
-
92004B92004-Y011 STUD, 6X28STUD, 6X28
-
9204392043-Y013 PIN, 10X16PIN, 10X16
-
9205592055-Y007 RING-O, 23X2.4RING-O, 23X2.4
-
92055A92055-Y008 RING-O, 22X2.0RING-O, 22X2.0
-
9207092070-Y002 PLUG-SPARK, CR7HSAPLUG-SPARK, CR7HSA
-
9209392093-Y001 SEALSEAL
-
9215392153-Y027 BOLT, FLANGE, 6X25BOLT, FLANGE, 6X25
-
92153A92153-Y029 BOLT, FLANGE, 6X35BOLT, FLANGE, 6X35
-
92153B92153-Y030 BOLT, FLANGE, 6X50BOLT, FLANGE, 6X50
-
92153C92153-Y051 BOLT, FLANGE, 6X25BOLT, FLANGE, 6X25
-
92153D92153-Y056 BOLT, FLANGE, 6X95BOLT, FLANGE, 6X95
-
92153E92153-Y065 BOLT, FLANGE, 6X25BOLT, FLANGE, 6X25
-
92153F92153-Y066 BOLT, FLANGE, 6X40BOLT, FLANGE, 6X40
-
9217292172-Y003 SCREWSCREW
-
9220092200-Y009 WASHER, 8MMWASHER, 8MM
-
9221092210-Y004 NUTNUT
-
92210A92210-Y027 NUT, 6MMNUT, 6MM
-
92210B92210-Y028 NUT, 8MMNUT, 8MM
-
92210C92210-Y035 NUT, 6MMNUT, 6MM
