CARBURETOR для Kawasaki KX 125 - 2000 года выпуска
-
№АртикулНазвание
-
1106011060-1254 GASKET, FLOAT CHAMBERGASKET, FLOAT CHAMBER
-
1315913159-1063 CONNECTOR, THROTTLE CABLECONNECTOR, THROTTLE CABLE
-
1500315003-1523 CARBURETOR, ASSY.CARBURETOR, ASSY.
-
1600516005-1084 TOP, CHAMBERTOP, CHAMBER
-
1601416014-1058 SCREW, PILOT AIRSCREW, PILOT AIR
-
1601616016-1085 PLUNGERPLUNGER
-
1602116021-1198 SCREW, THROTTLE STOPSCREW, THROTTLE STOP
-
1602516025-1214 VALVE, THROTTLE, #5 (OPT)VALVE, THROTTLE, #5 (OPT)
-
16025A16025-1215 VALVE, THROTTLE, #6VALVE, THROTTLE, #6
-
16025B16025-1216 VALVE, THROTTLE, #7 (OPT)VALVE, THROTTLE, #7 (OPT)
-
1603016030-1057 VALVE, FLOATVALVE, FLOAT
-
1603116031-1100 FLOATFLOAT
-
1604416044-007 CLAMP, FLOAT VALVECLAMP, FLOAT VALVE
-
1604916049-1051 COVER, MAIN JETCOVER, MAIN JET
-
1606516065-1369 HOLDER, CARBURETORHOLDER, CARBURETOR
-
1615916159-1053 JET, POWER, #50 (OPT)JET, POWER, #50 (OPT)
-
16159A16159-1054 JET, POWER, #55 (CANADA ONLY)JET, POWER, #55 (CANADA ONLY)
-
16159B16159-1055 JET, POWER, #52 (OPT)JET, POWER, #52 (OPT)
-
16159C16159-1056 JET, POWER, #58 (OPT)JET, POWER, #58 (OPT)
-
16159D16159-1057 JET, POWER, #60 (OPT)JET, POWER, #60 (OPT)
-
16159E16159-1059 JET, POWER, #42 (US ONLY)JET, POWER, #42 (US ONLY)
-
16159F16159-1059 JET, POWER, #42 (CANADA ONLY) (OPT)JET, POWER, #42 (CANADA ONLY) (OPT)
-
1617016170-1056 LINK, ASSY.LINK, ASSY.
-
1618716187-1082 NEEDLE, JET, N7NG (OPT)NEEDLE, JET, N7NG (OPT)
-
16187A16187-1083 NEEDLE, JET, N7NH (OPT)NEEDLE, JET, N7NH (OPT)
-
16187B16187-1084 NEEDLE, JET, N7NWNEEDLE, JET, N7NW
-
16187C16187-1085 NEEDLE, JET, N7NJ (OPT)NEEDLE, JET, N7NJ (OPT)
-
16187D16187-1086 NEEDLE, JET, N7NK (OPT)NEEDLE, JET, N7NK (OPT)
-
16187E16187-1087 NEEDLE, JET, N7PG (OPT)NEEDLE, JET, N7PG (OPT)
-
16187F16187-1088 NEEDLE, JET, N7PH (OPT)NEEDLE, JET, N7PH (OPT)
-
16187G16187-1089 NEEDLE, JET, N7PW (OPT)NEEDLE, JET, N7PW (OPT)
-
16187H16187-1090 NEEDLE, JET, N7PJ (OPT)NEEDLE, JET, N7PJ (OPT)
-
16187I16187-1091 NEEDLE, JET, N7PK (OPT)NEEDLE, JET, N7PK (OPT)
-
2117621176-1089 SENSORSENSOR
-
2118821188-1005 SOLENOIDSOLENOID
-
9200992009-1781 SCREWSCREW
-
92009A92009-1833 SCREW, CLAMPSCREW, CLAMP
-
92009B92009-1889 SCREWSCREW
-
9203692036-018 RING, SNAPRING, SNAP
-
9203792037-1396 CLAMP, TUBECLAMP, TUBE
-
92037A92037-1401 CLAMP, JET NEEDLECLAMP, JET NEEDLE
-
92037B92037-147 CLAMP, TUBECLAMP, TUBE
-
9205592055-1002 O-RING, PILOT ADJUSTO-RING, PILOT ADJUST
-
92055A92055-1167 O-RING, MAIN JET COVERO-RING, MAIN JET COVER
-
92055B92055-1580 O-RINGO-RING
-
9206392063-1366 JET, MAIN, #155 (OPT)JET, MAIN, #155 (OPT)
-
92063A92063-1367 JET, MAIN, #158 (OPT)JET, MAIN, #158 (OPT)
-
92063B92063-1368 JET, MAIN, #160JET, MAIN, #160
-
92063C92063-1369 JET, MAIN, #162 (OPT)JET, MAIN, #162 (OPT)
-
92063D92063-1370 JET, MAIN, #165 (OPT)JET, MAIN, #165 (OPT)
-
92063E92063-1372 JET, MAIN, #170 (OPT)JET, MAIN, #170 (OPT)
-
9206492064-1140 JET, PILOT, #40 (US ONLY)JET, PILOT, #40 (US ONLY)
-
92064A92064-1140 JET, PILOT, #40 (CANADA ONLY) (OPT)JET, PILOT, #40 (CANADA ONLY) (OPT)
-
92064C92064-1142 JET, PILOT, #45 (CANADA ONLY)JET, PILOT, #45 (CANADA ONLY)
-
132132G0620 BOLT, FLANGED, SMALLBOLT, FLANGED, SMALL
-
220220D0414 SCREW, PAN, CROSSCREW, PAN, CROS
-
92064D92064-1143 JET, PILOT, #48 (OPT)JET, PILOT, #48 (OPT)
-
92064E92064-1144 JET, PILOT, #50 (OPT)JET, PILOT, #50 (OPT)
-
9208192081-1555 SPRING, ADJUST SCREWSPRING, ADJUST SCREW
-
9214392143-1201 COLLAR, THROTTLE VALVECOLLAR, THROTTLE VALVE
-
9214592145-1242 SPRING, THROTTLE VALVESPRING, THROTTLE VALVE
-
9215192151-1507 BOLTBOLT
-
9217092170-1582 CLAMPCLAMP
-
9217192171-1077 CLAMPCLAMP
-
92171A92171-1105 CLAMPCLAMP
-
9219192191-1254 TUBE, 4X7X480TUBE, 4X7X480
-
92191A92191-1255 TUBE, AIR VENTTUBE, AIR VENT
-
92191B92191-1256 TUBE, 3.5X6.5X330TUBE, 3.5X6.5X330
-
92191C92191-1331 TUBE, 5.3X10.5X150TUBE, 5.3X10.5X150
-
9220092200-1369 WASHERWASHER
-
92200A92200-1466 WASHERWASHER
