GEAR CHANGE DRUM W/ SHIFT FORK(S) для Kawasaki KX 60 - 2000 года выпуска
-
№АртикулНазвание
-
220220B0614 SCREW, PAN, CROS, 6X14SCREW, PAN, CROS, 6X14
-
1309113091-1098 HOLDER, CHANGE DRUM PINHOLDER, CHANGE DRUM PIN
-
1314013140-1300 FORK, SHIFT, INPUTFORK, SHIFT, INPUT
-
13140A13140-1301 FORK, SHIFT, OUTPUTFORK, SHIFT, OUTPUT
-
1316913169-1309 PLATE, CHANGE DRUM POSITIONPLATE, CHANGE DRUM POSITION
-
1323913239-1065 DRUM, ASSY., CHANGEDRUM, ASSY., CHANGE
-
4904749047-1009 ROD, SHIFT, 10X90ROD, SHIFT, 10X90
-
9204292042-029 PIN, DOWEL, 4X16.8PIN, DOWEL, 4X16.8
