OIL PUMP для Kawasaki KLX250SF (KLX250WAF) - 2009 года выпуска
-
№АртикулНазвание
-
220220AA0610 SCREW-PAN-CROSS,6X10SCREW-PAN-CROSS,6X10
-
220A220AA0625 SCREW-PAN-CROSS,6X25SCREW-PAN-CROSS,6X25
-
220B220AA0630 SCREW-PAN-CROSS,6X30SCREW-PAN-CROSS,6X30
-
670670D2010 O RINGO RING
-
1101211012-1915 CAP,OIL FILTERCAP,OIL FILTER
-
1321613216-1193 GEAR-COMP,OIL PUMPGEAR-COMP,OIL PUMP
-
1608216082-1163 PUMP-ASSY-OILPUMP-ASSY-OIL
-
1614216142-1123 COVER-PUMPCOVER-PUMP
-
1615416154-1130 ROTOR-PUMPROTOR-PUMP
-
4906549065-1058 FILTER-OILFILTER-OIL
-
5201052010-1053 ELEMENT-OIL FILTERELEMENT-OIL FILTER
-
9203392033-1327 RING-SNAP,6MMRING-SNAP,6MM
-
9204292042-007 PIN,DOWEL,6.3X8X14PIN,DOWEL,6.3X8X14
-
9205592055-074 RING-O,OD=13RING-O,OD=13
-
92055A92055-1577 RING-O,52.6X2.4RING-O,52.6X2.4
-
9214492144-1761 SPRINGSPRING
-
9215392153-0695 BOLT,6X16BOLT,6X16
-
9220092200-1591 WASHER,8.5X12X1.0WASHER,8.5X12X1.0
