FUEL TANK для Kawasaki KLX140 (KLX140AGF) - 2016 года выпуска
-
№АртикулНазвание
-
132132BA0612 BOLT-FLANGED-SMALL,6X12BOLT-FLANGED-SMALL,6X12
-
4304943049-1102 PACKING,VALVEPACKING,VALVE
-
51001A51001-0822 TANK-COMP-FUELTANK-COMP-FUEL
-
5102351023-0030 TAP-ASSY,FUELTAP-ASSY,FUEL
-
5104851048-0009 CAP-ASSY-TANK,FUELCAP-ASSY-TANK,FUEL
-
9200992009-1123 SCREW,3X5SCREW,3X5
-
92009A92009-1971 SCREW,6MMSCREW,6MM
-
9202292022-1690 WASHER,6.5X24X2WASHER,6.5X24X2
-
9202792027-1966 COLLAR,6.8X10X14COLLAR,6.8X10X14
-
9205592055-1111 RING-O,FUEL TAP LEVERRING-O,FUEL TAP LEVER
-
92055A92055-1112 RING-O,FUEL TAP PACKINGRING-O,FUEL TAP PACKING
-
9207292072-0109 BAND,FUEL TANKBAND,FUEL TANK
-
9215192151-1930 BOLT,FLANGED-SMALL,6X25BOLT,FLANGED-SMALL,6X25
-
9215292152-0569 COLLARCOLLAR
-
9216092160-1328 DAMPER,FUEL TANKDAMPER,FUEL TANK
-
92160A92160-1397 DAMPER,FUEL TANK, REARDAMPER,FUEL TANK, REAR
-
9216192161-0336 DAMPERDAMPER
-
92161A92161-1523 DAMPERDAMPER
-
9219292192-0161 TUBETUBE
