SIDE COVERS W/ CHAIN COVER для Kawasaki NINJA ZX-10R (ZX1000FAFA) - 2010 года выпуска
-
№АртикулНазвание
-
1105511055-0115 BRACKET,TAIL COVER, LEFT HANDBRACKET,TAIL COVER, LEFT HAND
-
11055A11055-0116 BRACKET,TAIL COVER, RIGHT HANDBRACKET,TAIL COVER, RIGHT HAND
-
1409114091-0803-6Z COVER,TAIL LAMP,F.BLACKCOVER,TAIL LAMP,F.BLACK
-
1614616146-0074-6Z COVER-ASSY,TAIL,F.BLACKCOVER-ASSY,TAIL,F.BLACK
-
2701227012-0115 HOOKHOOK
-
3600136001-0126-660 COVER-SIDE, LEFT HAND,M.S.BLACKCOVER-SIDE, LEFT HAND,M.S.BLACK
-
36001A36001-0127-660 COVER-SIDE, RIGHT HAND,M.S.BLACKCOVER-SIDE, RIGHT HAND,M.S.BLACK
-
3601436014-0038 CASE-CHAINCASE-CHAIN
-
3604036040-0073-660 COVER-TAIL, LEFT HAND,M.S.BLACKCOVER-TAIL, LEFT HAND,M.S.BLACK
-
36040A36040-0074-660 COVER-TAIL, RIGHT HAND,M.S.BLACKCOVER-TAIL, RIGHT HAND,M.S.BLACK
-
36040B36040-0075-660 COVER-TAIL,CNT,M.S.BLACKCOVER-TAIL,CNT,M.S.BLACK
-
36040C36040-0076-6Z COVER-TAIL,UPP,F.BLACKCOVER-TAIL,UPP,F.BLACK
-
9201592015-1233 NUT,FLANGED,6MM,BLACKNUT,FLANGED,6MM,BLACK
-
92015A92015-1757 NUT,WELL,5MMNUT,WELL,5MM
-
9202292022-183 WASHER,6.2X11X1.5WASHER,6.2X11X1.5
-
9203992039-0051 RIVETRIVET
-
92039A92039-0068 RIVETRIVET
-
9215192151-1219 BOLT,SOCKET,6X12BOLT,SOCKET,6X12
-
92151A92151-1654 BOLT,SOCKET,6X14BOLT,SOCKET,6X14
-
9215392153-1356 BOLT,SOCKET,6X22BOLT,SOCKET,6X22
-
92153A92153-1675 BOLT,SOCKET,6X18BOLT,SOCKET,6X18
-
9215492154-0209 BOLT,SOCKET,5X16BOLT,SOCKET,5X16
-
9216092160-1613 DAMPERDAMPER
-
9216192161-0208 DAMPER,FUEL TANK BRACKETDAMPER,FUEL TANK BRACKET
-
92161A92161-0301 DAMPERDAMPER
-
92161B92161-1177 DAMPERDAMPER
