HANDLEBAR для Kawasaki VULCAN 900 CUSTOM (VN900CBF) - 2011 года выпуска
-
№АртикулНазвание
-
220220R0525 SCREW-PAN-CROSS, 5X25SCREW-PAN-CROSS, 5X25
-
1328013280-1101 HOLDER, CLUTCH LEVERHOLDER, CLUTCH LEVER
-
2701027010-1268 SWITCH, CLUTCHSWITCH, CLUTCH
-
4600346003-0115 HANDLEHANDLE
-
4601946019-1123 GRIP-ASSY, THROTTLEGRIP-ASSY, THROTTLE
-
4605546055-003 SCREW, CABLE ADJUST, 8MMSCREW, CABLE ADJUST, 8MM
-
4605646056-005 NUT, CABLE ADJUST LOCK, 8MMNUT, CABLE ADJUST LOCK, 8MM
-
4607546075-1212 GRIP (LEFT)GRIP (LEFT)
-
46076A46076-0075 LEVER-ASSY-GRIP, CLUTCHLEVER-ASSY-GRIP, CLUTCH
-
46091B46091-0230 HOUSING-ASSY-CONTROL (LEFT)HOUSING-ASSY-CONTROL (LEFT)
-
46091C46091-0232 HOUSING-ASSY-CONTROL (RIGHT)HOUSING-ASSY-CONTROL (RIGHT)
-
4609246092-1204 LEVER-GRIP, CLUCTHLEVER-GRIP, CLUCTH
-
5600156001-0088 MIREAROR-ASSY (LEFT)MIREAROR-ASSY (LEFT)
-
56001A56001-0104 MIREAROR-ASSY (RIGHT)MIREAROR-ASSY (RIGHT)
-
9201592015-1191 NUT, LOCK, 6MM (BLACK)NUT, LOCK, 6MM (BLACK)
-
9203792037-1163 CLAMP, SPEED, L=58CLAMP, SPEED, L=58
-
9214392143-1351 COLLARCOLLAR
-
9215392153-0716 BOLT, LEVER SETBOLT, LEVER SET
-
92153A92153-0721 BOLT, 6X20BOLT, 6X20
-
9217292172-0164 SCREW, 3X20SCREW, 3X20
-
92210A92210-1139 NUT, LOCK, FLANGED, 10MMNUT, LOCK, FLANGED, 10MM
