CYLINDER HEAD для Kawasaki NINJA ZX-10RR (ZX1002GKF) - 2019 года выпуска
-
№АртикулНазвание
-
1100411004-0779 GASKET-HEADGASKET-HEAD
-
1100811008-0951 HEAD-COMP-CYLINDERHEAD-COMP-CYLINDER
-
120120CD0630 BOLT-SOCKET, 6X30BOLT-SOCKET, 6X30
-
1606616066-0013 HOLDER-THROTTLE BODYHOLDER-THROTTLE BODY
-
4900249002-0009 GUIDE-VALVEGUIDE-VALVE
-
9200492004-0049 STUD, 8X18STUD, 8X18
-
9204292042-007 PIN, DOWEL, 6.3X8X14PIN, DOWEL, 6.3X8X14
-
9204392043-1264 PIN, 8.2X10X14PIN, 8.2X10X14
-
9205592055-0074 RING-O, 25.5X2RING-O, 25.5X2
-
92055A92055-0914 RING-O, 50X1.9RING-O, 50X1.9
-
9206592065-096 GASKETGASKET
-
9206692066-0129 PLUG, 16X10PLUG, 16X10
-
9215392153-0454 BOLT, TORX, 6X18BOLT, TORX, 6X18
-
92153A92153-0656 BOLT, SOCKET, 6X45BOLT, SOCKET, 6X45
-
92153B92153-1044 BOLT, FLANGED, 10X90BOLT, FLANGED, 10X90
-
9215492154-3844 BOLT, SOCKET, 10X10BOLT, SOCKET, 10X10
-
92154A92154-3846 BOLT, SOCKET, 5X14BOLT, SOCKET, 5X14
-
9217392173-0222 CLAMPCLAMP
-
9220092200-0114 WASHER, 10.5X19X2.3WASHER, 10.5X19X2.3
