FUEL TANK для Kawasaki MULE 550 (KAF300-C4) - 2000 года выпуска
-
№АртикулНазвание
-
130130D0830 BOLT-FLANGED, 8X30BOLT-FLANGED, 8X30
-
1100911009-1755 GASKET, FUEL GAUGEGASKET, FUEL GAUGE
-
1402414024-1697 COVER, FUEL GAUGECOVER, FUEL GAUGE
-
5100151001-1465 TANK-COMP-FUELTANK-COMP-FUEL
-
5104851048-1103 CAP-ASSY-TANK, FUELCAP-ASSY-TANK, FUEL
-
5200552005-1098 GAUGE, FUELGAUGE, FUEL
-
9200992009-1541 SCREW, 6X14SCREW, 6X14
-
9201592015-1397 NUT, LOCK, FLANGED, 8MMNUT, LOCK, FLANGED, 8MM
-
9202292022-1632 WASHER, 9X28X2.3WASHER, 9X28X2.3
-
9202792027-1081 COLLAR, 8.8X12X15.5COLLAR, 8.8X12X15.5
-
9207592075-1736 DAMPERDAMPER
